Home / Car Parts / Braking / Brake Pads & Discs / Brake Pads
Apec Blue PD3416 Brake Pad Set, disc brake - 1
Apec Blue PD3416 Brake Pad Set, disc brake - 1
APEC BLUE

Apec Blue PD3416 Brake Pad Set, disc brake

SKU: PD3416
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£19.85 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

BMW
5 (E39)
Description Cylinder Capacity Horse Power Year
520 i 1990 CCM 150 HP 01/1996 - 06/2003
525 tds 2497 CCM 143 HP 01/1996 - 06/2003
523 i 2494 CCM 170 HP 09/1995 - 08/2000
528 i 2793 CCM 193 HP 09/1995 - 08/2000
540 i 4398 CCM 286 HP 03/1996 - 06/2003
535 i 3498 CCM 235 HP 06/1996 - 08/1998
525 td 2497 CCM 116 HP 01/1997 - 06/2003
530 d 2926 CCM 184 HP 08/1998 - 09/2000
535 i 3498 CCM 245 HP 09/1998 - 06/2003
520 i 1990 CCM 136 HP 01/1996 - 06/2003
520 d 1951 CCM 136 HP 02/2000 - 06/2003
525 d 2497 CCM 163 HP 02/2000 - 06/2003
520 i 2171 CCM 170 HP 09/2000 - 06/2003
530 d 2926 CCM 193 HP 09/1998 - 06/2003
5 Touring (E39)
Description Cylinder Capacity Horse Power Year
520 i 1990 CCM 150 HP 03/1997 - 08/2001
523 i 2494 CCM 170 HP 03/1997 - 08/2000
540 i 4398 CCM 286 HP 04/1997 - 12/2003
528 i 2793 CCM 193 HP 11/1996 - 08/2000
530 d 2926 CCM 184 HP 08/1998 - 09/2000
525 tds 2497 CCM 143 HP 03/1997 - 05/2004
520 i 1990 CCM 136 HP 03/1997 - 08/2001
520 d 1951 CCM 136 HP 02/2000 - 09/2003
525 d 2497 CCM 163 HP 02/2000 - 05/2004
530 d 2926 CCM 193 HP 09/2000 - 05/2004
520 i 2171 CCM 170 HP 09/2000 - 12/2003
525 i 2494 CCM 192 HP 09/2000 - 05/2004
530 i 2979 CCM 231 HP 09/2000 - 12/2003
520 i 2171 CCM 163 HP 09/2000 - 12/2003
523 i 2494 CCM 163 HP 09/1998 - 08/2000

The Apec Blue PD3416 Brake Pad Set, disc brake is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records ATE brake-system specification, with retaining spring, test mark 90R-02A01400/47011, and rear axle fitting position. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Pad Set, disc brake
Brake System : ATE
Supplementary Article/Supplementary Info : with retaining spring
Width [mm] : 123
Width 2 [mm] : 122
Height 1 [mm] : 45
Thickness [mm] : 17
Test Mark : 90R-02A01400/47011
Wear Warning Contact : prepared for wear warning indicator
Fitting Position : Rear Axle
  • Vendor APEC BLUE
  • SKU PD3416
  • Barcode 5028906129002
  • BMW : 34211163395 34212157591 34212157592 34216761281
  • APEC : PAD942
  • APEC : PD3416
  • BLUE PRINT : ADB114234
  • BORG & BECK : BBP1591
  • BOSCH : 0 986 494 009
  • BREMBO : P 06 023
  • DELPHI : LP1107
  • FEBI BILSTEIN : 16190
  • HELLA : 8DB 355 007-981
  • MEYLE : 025 216 9117
  • MEYLE : 025 216 9117/PD
  • MINTEX : MDB1879
  • National : NP2939
  • TEXTAR : 2169103
  • TEXTAR : 2169181
