Apec Blue PD3704 Brake Pad Set, disc brake - 1
Apec Blue PD3704 Brake Pad Set, disc brake - 1
APEC BLUE

Apec Blue PD3704 Brake Pad Set, disc brake

SKU: PD3704
Your selected vehicle
Only 2 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£42.04 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

MERCEDES-BENZ
GL-CLASS (X166)
Description Cylinder Capacity Horse Power Year
GL 350 CDI / BlueTec 4-matic (166.823, 166.824) 2987 CCM 258 HP 07/2012 - 10/2015
GL 500 4-matic (166.873) 4663 CCM 435 HP 07/2012 - 10/2015
GLE Coupe (C292)
Description Cylinder Capacity Horse Power Year
350 d 4-matic (292.323, 292.324) 2987 CCM 258 HP 03/2015 - 10/2019
400 4-matic (292.356) 2996 CCM 333 HP 03/2015 - 10/2019
GLE (W166)
Description Cylinder Capacity Horse Power Year
400 4-matic (166.056) 2996 CCM 333 HP 04/2015 - 10/2018
250 d (166.006) 2143 CCM 204 HP 04/2015 - 10/2018
250 d 4-matic (166.004) 2143 CCM 204 HP 04/2015 - 10/2018
350 d 4-matic (166.024) 2987 CCM 258 HP 04/2015 - 10/2018
GLS (X166)
Description Cylinder Capacity Horse Power Year
350 d 4-matic (166.824) 2987 CCM 258 HP 11/2015 - 04/2019
400 4-matic (166.856) 2996 CCM 333 HP 11/2015 - 04/2019
500 4-matic (166.873) 4663 CCM 456 HP 11/2015 - 04/2019
M-CLASS (W166)
Description Cylinder Capacity Horse Power Year
ML 250 CDI / BlueTEC 4-matic (166.004, 166.003) 2143 CCM 204 HP 06/2011 - 12/2015
ML 350 BlueTEC 4-matic (166.024, 166.023) 2987 CCM 258 HP 06/2011 - 02/2015
ML 350 4-matic (166.057) 3498 CCM 306 HP 06/2011 - 12/2015
ML 400 4-matic (166.056) 2996 CCM 333 HP 08/2013 - 02/2015

The Apec Blue PD3704 Brake Pad Set, disc brake is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records ATE brake-system specification, with retaining spring, test mark 90R-02A01398/42469, and front axle fitting position. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Pad Set, disc brake
Brake System : ATE
Supplementary Article/Supplementary Info : with retaining spring
Width [mm] : 193
Height 1 [mm] : 64
Thickness [mm] : 19
Test Mark : 90R-02A01398/42469
Wear Warning Contact : prepared for wear warning indicator
Fitting Position : Front Axle
  • Vendor APEC BLUE
  • SKU PD3704
  • Barcode 5028906131876
  • MERCEDES-BENZ : 0004203302 0004209600 0064203920 0074208020 0074208120 0774208020 A0004203302 A0004209600 A0064203920 A0074208020 A0074208120 A0774208020
  • APEC : PAD1924
  • APEC : PAD1924B
  • APEC : PD3704
  • BLUE PRINT : ADU174215
  • BORG & BECK : BBP2491
  • BOSCH : 0 986 494 672
  • BREMBO : P 50 109
  • BREMBO : P50109NX
  • Fahren : FBP3704
  • FEBI BILSTEIN : 16900
  • HELLA : 8DB 355 019-701
  • MEYLE : 025 251 9219/PD
  • MINTEX : MDB3239
  • NAPA : NBP1251
  • National : NP3174
  • SKF : VKBP 80389
  • TEXTAR : 2519202
