Apec Blue PD3783 Brake Pad Set, disc brake - 1
Apec Blue PD3783 Brake Pad Set, disc brake - 1
APEC BLUE

Apec Blue PD3783 Brake Pad Set, disc brake

SKU: PD3783
Your selected vehicle
Only 2 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£33.70 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

JAGUAR
F-PACE (X761)
Description Cylinder Capacity Horse Power Year
3.0 SCV6 AWD 2995 CCM 340 HP From 09/2015
3.0 SCV6 AWD 2995 CCM 380 HP From 09/2015
3.0 SDV6 AWD 2993 CCM 300 HP From 09/2015
2.0 TD4 1999 CCM 180 HP From 09/2015
2.0 TD4 AWD 1999 CCM 180 HP From 09/2015
2.0 TD4 1999 CCM 163 HP From 02/2017
2.0 SD4 AWD 1999 CCM 241 HP From 02/2017
2.0 Ti4 AWD 1997 CCM 250 HP From 02/2017
2.0 Ti4 AWD 1997 CCM 300 HP From 06/2017
2.0 Ti4 1997 CCM 250 HP From 09/2017
2.0 D165 MHEV 1997 CCM 163 HP From 10/2020
2.0 D200 MHEV 1997 CCM 204 HP From 10/2020
3.0 D300 MHEV 2997 CCM 300 HP From 10/2020
3.0 P400 MHEV 2996 CCM 400 HP From 10/2020
I-PACE (X590)
Description Cylinder Capacity Horse Power Year
EV400 AWD 400 HP From 02/2018
EV320 AWD 321 HP From 10/2020
XE (X760)
Description Cylinder Capacity Horse Power Year
2.0 1999 CCM 241 HP From 03/2015
3.0 S 2995 CCM 340 HP From 03/2015
2.0 D AWD 1999 CCM 241 HP From 02/2017
2.0 1997 CCM 250 HP From 02/2017
2.0 AWD 1997 CCM 250 HP From 02/2017
3.0 S 2995 CCM 381 HP From 02/2017
2.0 AWD 1997 CCM 300 HP From 06/2017
2.0 1997 CCM 300 HP From 06/2017
XF II (X260)
Description Cylinder Capacity Horse Power Year
3.0 2995 CCM 340 HP From 05/2015
3.0 2995 CCM 380 HP From 05/2015
2.0 1999 CCM 241 HP From 05/2015
3.0 D 2993 CCM 300 HP From 05/2015
3.0 AWD 2995 CCM 340 HP From 07/2015
3.0 AWD 2995 CCM 380 HP From 07/2015
2.0 1997 CCM 250 HP From 03/2017
2.0 AWD 1997 CCM 250 HP From 03/2017
2.0 AWD 1997 CCM 300 HP From 09/2017
XF SPORTBRAKE (X260)
Description Cylinder Capacity Horse Power Year
2.0 D 1999 CCM 163 HP From 07/2017
2.0 D 1999 CCM 180 HP From 07/2017
2.0 D AWD 1999 CCM 180 HP From 07/2017
2.0 D AWD 1999 CCM 241 HP From 07/2017
3.0 D 2993 CCM 300 HP From 07/2017
2.0 AWD 1997 CCM 300 HP From 08/2018
LAND ROVER
RANGE ROVER VELAR (L560)
Description Cylinder Capacity Horse Power Year
2.0 D180 TD4 4x4 1999 CCM 180 HP From 03/2017
2.0 D240 SD4 4x4 1999 CCM 241 HP From 03/2017
3.0 P380 SCV6 4x4 2995 CCM 380 HP From 03/2017
2.0 P250 Si4 4x4 1997 CCM 250 HP From 03/2017
3.0 D300 SDV6 4x4 2993 CCM 300 HP From 03/2017
2.0 P300 Si4 4x4 1997 CCM 300 HP From 03/2017
3.0 D275 SDV6 4x4 2993 CCM 275 HP From 04/2018
3.0 P340 SCV6 4x4 2995 CCM 340 HP From 04/2018
2.0 D200 MHEV 4x4 1997 CCM 204 HP From 07/2020
3.0 D300 MHEV 4x4 2997 CCM 300 HP From 07/2020
3.0 P400 MHEV 4x4 2995 CCM 400 HP From 07/2020
2.0 P400 Hybrid 4x4 1997 CCM 404 HP From 07/2020

The Apec Blue PD3783 Brake Pad Set, disc brake is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records with retaining spring, test mark 90R-02A01400/39398, front axle fitting position, and 350 mm for brake disc diameter. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Pad Set, disc brake
Supplementary Article/Supplementary Info : with retaining spring
Width [mm] : 180
Height 1 [mm] : 77
Thickness [mm] : 18
Test Mark : 90R-02A01400/39398
Wear Warning Contact : prepared for wear warning indicator
Fitting Position : Front Axle
for brake disc diameter [mm] : 350
for article number : SDK6964
  • Vendor APEC BLUE
  • SKU PD3783
  • Barcode 5028906132668
  • JAGUAR : J9D1118 J9D1199 T2H16147 T2H21043 T2H43857 T2H53848 T2H7448 T4A44837 T4A44841 T4N14764
  • LAND ROVER : LR064687 LR111385 LR141734 LR150620 LR160437 LR160444 LR160511
  • APEC : PAD2113
  • APEC : PAD2113B
  • APEC : PD3783
  • BLUE PRINT : ADJ134252
  • BORG & BECK : BBP2548
  • BOSCH : 0 986 494 829
  • BREMBO : P 36 031
  • DELPHI : LP5022EV
  • Fahren : FBP3783
  • FEBI BILSTEIN : 170389
  • HELLA : 8DB 355 024-661
  • MINTEX : MDB3836
  • NAPA : NBP1630
  • National : NP3055
  • SKF : VKBP 80977
  • TEXTAR : 2230201
  • VALEO : 610441
