Apec Blue PD3934 Brake Pad Set, disc brake - 1
Apec Blue PD3934 Brake Pad Set, disc brake - 1
APEC BLUE

Apec Blue PD3934 Brake Pad Set, disc brake

SKU: PD3934
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£21.75 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

SUBARU
SOLTERRA
Description Cylinder Capacity Horse Power Year
EV 218 HP From 06/2022
SUZUKI
ACROSS (A5Z_)
Description Cylinder Capacity Horse Power Year
2.5 Hybrid 2487 CCM 306 HP From 06/2020
TOYOTA
bZ4X (_EAM1_)
Description Cylinder Capacity Horse Power Year
EV (XEAM10) 204 HP From 12/2021
EV (YEAM15) 218 HP From 12/2021
HIGHLANDER (GSU7_, AXUH7_, TXUA7_)
Description Cylinder Capacity Horse Power Year
3.5 VVTi AWD (GSU75) 3456 CCM 249 HP From 12/2019
2.5 Hybrid AWD (AXUH78) 2487 CCM 246 HP From 12/2019
RAV 4 V (_A5_, _H5_)
Description Cylinder Capacity Horse Power Year
2.5 Hybrid (AXAH52) 2487 CCM 218 HP From 12/2018
2.5 VVTi AWD (AXAA54) 2487 CCM 203 HP From 12/2018
2.5 Hybrid AWD (AXAH54, AXAL54) 2487 CCM 222 HP From 12/2018
2.5 Hybrid AWD (AXAP54, AXAP54L) 2487 CCM 306 HP From 09/2020
LEXUS
NX II (_A2_, _H2_)
Description Cylinder Capacity Horse Power Year
350h (AAZH20) 2487 CCM 243 HP From 09/2021
350h E-Four (AAZH25) 2487 CCM 243 HP From 09/2021
450h+ E-Four (AAZH26) 2487 CCM 309 HP From 09/2021
RX (_LA1_, _LH1_)
Description Cylinder Capacity Horse Power Year
500h DIRECT4 (TALH17) 2393 CCM 371 HP From 06/2022
350h E-Four (AALH15) 2487 CCM 250 HP From 02/2023
450h+ E-Four (AALH16) 2487 CCM 309 HP From 12/2022
350h E-Four (AALH15) 2487 CCM 250 HP From 02/2023
RZ (_BM1_)
Description Cylinder Capacity Horse Power Year
450e DIRECT4 (XEBM15) 313 HP From 01/2023
300e (XEBM10) 204 HP From 12/2023
UX (_AA1_, _AH1_, _MA1_)
Description Cylinder Capacity Horse Power Year
300e (KMA10) 204 HP From 04/2020

The Apec Blue PD3934 Brake Pad Set, disc brake is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records 104 mm width, test mark 90R-02A01397/47513, not prepared for wear warning indicator, and rear axle fitting position. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Pad Set, disc brake
Width [mm] : 104
Height 1 [mm] : 47
Thickness [mm] : 14
Test Mark : 90R-02A01397/47513
Wear Warning Contact : not prepared for wear warning indicator
Fitting Position : Rear Axle
  • Vendor APEC BLUE
  • SKU PD3934
  • Barcode 5028906168261
  • SUZUKI : T04466F402 T04466F402000
  • TOYOTA : 0446602430 0446630360 0446630410 0446642090 04466F4020 446612160
  • LEXUS : 0446648170
  • APEC : PAD2308
  • APEC : PD3934
  • BLUE PRINT : ADBP420100
  • BORG & BECK : BBP2851
  • BORG & BECK : BBP2916
  • BOSCH : 0 986 460 043
  • BREMBO : P 83 174
  • DELPHI : LP3599
  • FEBI BILSTEIN : 180223
  • FTE : 9011255
  • HELLA : 8DB 355 040-121
  • MINTEX : MDB4217
  • NAPA : NBP1678
  • National : NP3187
  • SKF : VKBP 91405
  • TEXTAR : 2058201
  • VALEO : 302930
