APEC BLUE

Apec Blue SDK6197 Brake Disc

SKU: SDK6197

Your selected vehicle

In stock

Order by 17:00 for same-day dispatch

£18.72 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

MERCEDES-BENZ

A-CLASS (W168)

Description	Cylinder Capacity	Horse Power	Year
A 140 (168.031, 168.131)	1397 CCM	82 HP	07/1997 - 08/2004
A 160 (168.033, 168.133)	1598 CCM	102 HP	07/1997 - 08/2004
A 170 CDI (168.008)	1689 CCM	90 HP	07/1998 - 02/2001
A 190 (168.032, 168.132)	1898 CCM	125 HP	03/1999 - 08/2004
A 160 CDI (168.006)	1689 CCM	75 HP	02/2001 - 08/2004
A 170 CDI (168.009, 168.109)	1689 CCM	95 HP	02/2001 - 08/2004
A 140 (168.031, 168.131)	1598 CCM	82 HP	01/2001 - 08/2004

The Apec Blue SDK6197 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records vented disc construction, 260 mm outer diameter, 22 mm brake disc thickness, and 67 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc

Brake Disc Type : Vented

Outer Diameter [mm] : 260

Brake Disc Thickness [mm] : 22

Height [mm] : 40

Bolt Hole Circle Ø [mm] : 112

Centering Diameter [mm] : 67

Number of Holes : 5

Test Mark : 90R-02C0349/1401

APEC : DSK813
APEC : SDK6197
BLUE PRINT : ADU174326
BORG & BECK : BBD4110
BOSCH : 0 986 478 875
FEBI BILSTEIN : 17747
FEBI BILSTEIN : 22994
HELLA : 8DD 355 105-991
MEYLE : 015 521 2030
MINTEX : MDC1035
National : NBD920
SKF : VKBD 80119 V2
TEXTAR : 92091303

Apec Blue SDK6197 Brake Disc
