Apec Blue SDK6383 Brake Disc

SKU: SDK6383
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£53.62 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

RENAULT
ESPACE Mk IV (JK0/1_)
Description Cylinder Capacity Horse Power Year
2.0 Turbo (JK0A, JK0B, JK0N) 1998 CCM 163 HP 11/2002 - 02/2006
2.2 dCi (JK0H) 2188 CCM 150 HP 11/2002 - 08/2006
3.5 V6 (JK00, JK0F, JK0P, JK0S, JK0W) 3498 CCM 241 HP 11/2002 - 12/2015
3.0 dCi (JK0J, JK0V) 2958 CCM 177 HP 11/2002 - 08/2006
2.0 (JK09) 1998 CCM 136 HP 11/2002 - 01/2015
2.0 dCi (JK01, JK02, JK1J, JK1K, JK1H) 1995 CCM 150 HP 01/2006 - 12/2015
3.0 dCi (JK0E, JK0Y) 2958 CCM 181 HP 01/2006 - 01/2015
2.2 dCi (JK07) 2188 CCM 139 HP 02/2006 - 12/2015
2.0 dCi (JK02, JK03) 1995 CCM 131 HP 01/2006 - 12/2015
2.0 (JK0K) 1998 CCM 133 HP 11/2002 - 12/2015
3.0 dCi 2958 CCM 163 HP 09/2005 - 01/2015
VEL SATIS (BJ0_)
Description Cylinder Capacity Horse Power Year
2.0 16V Turbo (BJ0K) 1998 CCM 163 HP 06/2002 - 08/2009
3.5 V6 (BJ0R, BJ0V, BJ0U) 3498 CCM 241 HP 06/2002 - 08/2009
2.2 dCi (BJ0E, BJ0F) 2188 CCM 150 HP 06/2002 - 08/2009
3.0 dCi (BJ0J, BJ0N) 2958 CCM 177 HP 06/2002 - 06/2006
2.0 16 V Turbo 1998 CCM 170 HP 04/2004 - 08/2009

The Apec Blue SDK6383 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records vented disc construction, 324 mm outer diameter, 28 mm brake disc thickness, and 15 mm wheel bolt bore diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : Vented
Outer Diameter [mm] : 324
Brake Disc Thickness [mm] : 28
Height [mm] : 47
Bolt Hole Circle Ø [mm] : 108
Wheel Bolt Bore Diameter [mm] : 15
Centering Diameter [mm] : 61
Number of Holes : 5
  • Vendor APEC BLUE
  • SKU SDK6383
  • Barcode 5028906133924
  • RENAULT : 7701207357 8200177024 8200242318 8200570191 8201695235
  • APEC : DSK2242
  • APEC : SDK6383
  • BLUE PRINT : ADR164316
  • BORG & BECK : BBD5764S
  • BOSCH : 0 986 479 565
  • FEBI BILSTEIN : 24311
  • HELLA : 8DD 355 127-891
  • MEYLE : 16-15 521 0012
  • MINTEX : MDC1536
  • National : NBD1177
  • SKF : VKBD 80149 V1
  • TEXTAR : 92119405
