Apec Blue SDK6947 Brake Disc - 1
Apec Blue SDK6947 Brake Disc - 1
APEC BLUE

Apec Blue SDK6947 Brake Disc

SKU: SDK6947
Your selected vehicle
Out of stock
Out of Stock
£25.38 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

KIA
PICANTO III (JA)
Description Cylinder Capacity Horse Power Year
1.0 998 CCM 67 HP From 03/2017
1.2 1248 CCM 84 HP From 03/2017
1.0 T-GDi 998 CCM 100 HP From 03/2017
1.0 998 CCM 69 HP From 03/2017
1.0 LPG 998 CCM 65 HP From 11/2018
1.2 MPI 1197 CCM 84 HP From 07/2020
1.0 998 CCM 63 HP From 05/2024
1.2 DPI 1197 CCM 79 HP From 05/2024

The Apec Blue SDK6947 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records vented disc construction, 256 mm outer diameter, 20 mm brake disc thickness, and 62 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : Vented
Outer Diameter [mm] : 256
Brake Disc Thickness [mm] : 20
Height [mm] : 43
Bolt Hole Circle Ø [mm] : 100
Centering Diameter [mm] : 62
Number of Holes : 4
Test Mark : 90R-02C0349/0010
  • Vendor APEC BLUE
  • SKU SDK6947
  • Barcode 5028906148232
  • KIA : 51712G6300 KIA151
  • APEC : DSK3391
  • APEC : SDK6947
  • BLUE PRINT : ADG043234
  • BORG & BECK : BBD5528
  • BOSCH : 0 986 479 G86
  • Fahren : FBD6947
  • HELLA : 8DD 355 130-001
  • MEYLE : 28-15 521 0027
  • MINTEX : MDC2841C
  • NAPA : NBD5333
  • National : NBD2153
  • TEXTAR : 92295403
  • VALEO : 673405
