Bosch 0001109443 Starter Motor
Your selected vehicle
Regular price
£227.60
inc. VAT
Pay in 3 interest-free payments with Klarna
Standard delivery
Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.
The Bosch 0001109443 Starter Motor is a replacement starting or charging-system component that supports electrical power generation, storage or engine cranking in the vehicle. Its catalogue specification records 12 V electrical rating, 2.2 kW rated power, 11 teeth, and Self-supporting starter type. Match the reference, voltage, output or capacity, terminals, mounting and vehicle application before fitting; isolate the electrical system and follow the manufacturer's coding procedure where required.
Function :
Starter
Voltage [V] :
12
Rated Power [kW] :
2.2
Number of mounting bores :
0
Number of threaded holes :
3
Number of Teeth :
11
Clamp :
50
Clamp :
30
Flange Diameter [mm] :
66
Rotation Direction :
Clockwise rotation
Pinion Rest Position [mm] :
-5
Starter Type :
Self-supporting
Thread Size :
M10
Thread Size 1 :
M10x1.5
Thread Size 2 :
M10x1.5
Length [mm] :
241
Position/Degree :
links
Mounting Angle [degrees] :
56
Jaw opening angle measurement [Degree] :
36
Mounting bore angle measurement [degree] :
56
- Vendor BOSCH
- SKU 0001109443
- ALFA ROMEO : 1473638080 1475489080 9611705880
- CITROËN : 14 754 890 80 5802 CL 5802 F6 5802 F7 5802 G4 5802 H6 5802 L7 5802 M5 5802 S8 96 253 824
- DAF : 1516821R
- FIAT : K1473638080 K1475489080 K9611705880 K9625382480 1473638080 1475489080 9611705880 9625382480
- LANCIA : K1473638080 K1475489080 K9611705880 K9625382480 1473638080 1475489080 9611705880 9625382480
- PEUGEOT : 14 754 890 80 5802 CL 5802 F6 5802 F7 5802 G4 5802 H6 5802 L7 5802 M5 5802 S8 96 253 824
- APEC : ASM1564
- BOSCH : 0 986 016 950
- BOSCH : 1 986 S00 754
- Carwood Group : BREF0320986016950
- Carwood Group : BREF032112053
- Carwood Group : BREF0321986S00754
- FEBI BILSTEIN : 101568
- FEBI BILSTEIN : 192987
- HELLA : 8EA 011 611-061
- LUCAS : LRT00108
- NAPA : NSM1564
- VALEO : 438186
- WAI : 31102N
- WAI : S131.673
- BOSCH : R78-M45 12V (R)
