BOSCH

Bosch 0204114047 Brake Shoe Set

SKU: 0204114047
Your selected vehicle
Only 4 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£68.80 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

FORD
COURIER Box Body/MPV (F3L, F5L)
Description Cylinder Capacity Horse Power Year
1.8 D 1753 CCM 60 HP 09/1991 - 02/1996
1.3 1299 CCM 60 HP 09/1991 - 02/1996
FIESTA Hatchback Van (FVD)
Description Cylinder Capacity Horse Power Year
1.8 D (FVJ) 1753 CCM 60 HP 03/1989 - 12/1995
1.1 1119 CCM 50 HP 12/1991 - 08/1995
1.0 999 CCM 45 HP 04/1989 - 12/1991
1.1 1119 CCM 54 HP 04/1989 - 12/1992
FIESTA Mk III (GFJ)
Description Cylinder Capacity Horse Power Year
1.1 1119 CCM 55 HP 03/1989 - 12/1995
1.4 1392 CCM 73 HP 03/1989 - 12/1995
1.8 D 1753 CCM 60 HP 03/1989 - 12/1995
1.1 1119 CCM 50 HP 03/1989 - 12/1995
1.3 Cat 1299 CCM 60 HP 05/1991 - 01/1997
1.4 1391 CCM 71 HP 03/1989 - 12/1995
1.0 1001 CCM 45 HP 03/1989 - 12/1995
1.3 1299 CCM 60 HP 03/1989 - 12/1992

The Bosch 0204114047 Brake Shoe Set is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records Pre-assembled mounting type, 180 mm inner brake drum diameter, 17.46 mm piston diameter, and rear axle fitting position. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Shoe Set
Mounting Type : Pre-assembled
Adjustment : with automatic adjustment
Supplementary Article/Supplementary Info : with accessories
Brake Lining : with lining
Supplementary Article/Supplementary Info : with wheel brake cylinder
Inner brake drum diameter [mm] : 180
Width [mm] : 30
Piston Diameter [mm] : 17.46
Fitting Position : Rear Axle
  • Vendor BOSCH
  • SKU 0204114047
  • Barcode 3165141192834
  • BREMBO : K 24 027
  • MINTEX : MSP061
  • TEXTAR : 84041900
  • TRW : GSK1648
  • BOSCH : KS047
