BOSCH

Bosch 0204114602 Brake Shoe Set

SKU: 0204114602
Your selected vehicle
Only 1 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£50.73 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

FIAT
PUNTO (176_)
Description Cylinder Capacity Horse Power Year
55 1.1 1108 CCM 54 HP 09/1993 - 09/1999
75 1.2 1242 CCM 73 HP 10/1993 - 09/1999
1.7 TD 1698 CCM 71 HP 01/1994 - 09/1999
1.7 TD 1698 CCM 69 HP 01/1994 - 09/1999
60 1.2 (176AP, 176AR, 176AQ, 176BB) 1242 CCM 60 HP 09/1993 - 09/1999
1.7 TD (176AT) 1698 CCM 63 HP 09/1996 - 09/1999
1.2 16V 1242 CCM 86 HP 04/1997 - 09/1999
1.7 D 1698 CCM 57 HP 04/1994 - 09/1997
PUNTO Convertible (176_)
Description Cylinder Capacity Horse Power Year
60 1.2 (176AR_, 176BR_) 1242 CCM 60 HP 05/1995 - 06/2000
85 16V 1.2 1242 CCM 86 HP 04/1997 - 06/2000
PUNTO Van (176_)
Description Cylinder Capacity Horse Power Year
1.1 1108 CCM 54 HP 04/1996 - 02/2000
1.7 D 1698 CCM 57 HP 04/1996 - 02/2000
1.7 TD 1698 CCM 63 HP 09/1996 - 09/1999

The Bosch 0204114602 Brake Shoe Set is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records Pre-assembled mounting type, 180 mm inner brake drum diameter, 20.6 mm piston diameter, and rear axle fitting position. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Shoe Set
Mounting Type : Pre-assembled
Adjustment : with automatic adjustment
Supplementary Article/Supplementary Info : with accessories
Brake Lining : with lining
Supplementary Article/Supplementary Info : with wheel brake cylinder
Inner brake drum diameter [mm] : 180
Width [mm] : 30
Piston Diameter [mm] : 20.6
Manufacturer Restriction : Lockheed System
Engine Code : 176 B2.000
Engine Code : 176 A6.000
Construction Year from : 05.1997
Construction Year to : 08.1999
Fitting Position : Rear Axle
  • Vendor BOSCH
  • SKU 0204114602
  • Barcode 3165141176100
  • BORG & BECK : BBS1028K
  • BREMBO : K 23 028
  • HELLA : 8DB 355 004-311
  • MEYLE : 214 533 0045
  • MINTEX : MSP136
  • TEXTAR : 84049200
  • TRW : GSK1734
  • VALEO : 554629
  • BOSCH : KS602
