Bosch 0332201107 Relay, glow plug system
Your selected vehicle
Regular price
£8.75
inc. VAT
Pay in 3 interest-free payments with Klarna
Standard delivery
Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.
The Bosch 0332201107 Relay, glow plug system is a replacement engine ignition or starting-aid component that supports controlled combustion by providing the specified spark or pre-heating function. Its catalogue specification records 12 V electrical rating, IP5K4 protection type (ip code), -40 °C temperature range from, and 100 °C temperature range to. Confirm the reference, electrical rating, thread or connector details and engine application before fitting; use the specified installation torque and test procedure.
Function :
Relay, glow plug system
Current Strength [A] :
30
Voltage [V] :
12
Number of pins :
5
Relay function :
Normally open contact
Protection Type (IP Code) :
IP5K4
Switch Function :
Normally Open Contact
Temperature range from [°C] :
-40
Temperature range to [°C] :
100
Resistor [Ohm] :
16
- Vendor BOSCH
- SKU 0332201107
- ALFA ROMEO : 11130088 46520413
- AUDI : 4H0 951 253 C 7M0 951 253 C 7M0951253 8X0 951 253 A
- BMW : 61 31 6 919 113 7M0951253C
- CITROËN : 6555 HJ 96 730 621 80
- FIAT : 11130088 384114A1 46520413
- FORD : F5TZ14N089B 13A025C
- GMC : 13455281 19116059 19118886
- ISUZU : 8-97309-292-0
- LANCIA : 11130088 46520413
- MAGIRUS-DEUTZ : 01178985 117 8985
- MERCEDES-BENZ : A 000 623 86 23 A 002 542 12 19 A 002 542 28 19 A 002 542 85 19 A 002 542 86 19 A 003 542 02 19 A 004 545 29 05 A 638 821 00 47 000 623 86 23 002 542 12 19 002 542 28 19 002 542 85 19 002 542 86 19 003 542 02 19 004 545 29 05 638 821 00 47
- OPEL : 12 35 277 12 38 611 13100504 13266315 13266316 24435922 24460433 34 47 012 62 38 527 62 38 623 90338656 90414477 90464760 90511443 93172269
- SEAT : 4H0 951 253 C 7M0 951 253 C 7M0951253 8X0 951 253 A
- SKODA : 4H0 951 253 C 7M0 951 253 C 7M0951253 8X0 951 253 A
- TOYOTA : 90080 87020
- VAUXHALL : 12 35 277 12 38 611 13100504 13266315 34 47 012 62 38 527 62 38 623 90414477 90511443 93172269
- VOLVO : 222748 43733670
- VW : 4H0 951 253 C 7MO 951 253 C 7M0 951 253 C 7M0951253 8X0 951 253 A
- CHEVROLET : 13 455 281
- HYUNDAI : 95225 2D000 95225 38050 95230 2P040 95230 2P050
- CASE IH : 07077033 105849A1 7077033 84100707
- HITACHI : 132202 132203 2502203
- MASSEY FERGUSON : 4272431M1
- SAME : 01178985 04419536
- STEINBOCK : 51084979
- FERRARI : 161591 183662
- ROLLS-ROYCE : UD71832 UD75823
- FENDT : X 830 250 024 000 X830250069 4272431M1
- JOHN DEERE : AL61578 AL76702 AZ61578
- HOLDEN : 3447012 93 172 269
- BUICK : 13455281
- CADILLAC : 90511443 93172269
- STILL : 7916291277
- JUNGHEINRICH : 51084979
- FEBI BILSTEIN : 107803
- FEBI BILSTEIN : 40910
- MAHLE : MR 3
- MEYLE : 100 830 0016
- MEYLE : 114 830 0001
- BOSCH : MR107
