Bosch 0986020170 Starter Motor
Your selected vehicle
Regular price
£258.99
inc. VAT
Pay in 3 interest-free payments with Klarna
Standard delivery
Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.
The Bosch 0986020170 Starter Motor is a replacement starting or charging-system component that supports electrical power generation, storage or engine cranking in the vehicle. Its catalogue specification records 24 V electrical rating, 4 kW rated power, 10 teeth, and Self-supporting starter type. Match the reference, voltage, output or capacity, terminals, mounting and vehicle application before fitting; isolate the electrical system and follow the manufacturer's coding procedure where required.
Function :
Starter
Voltage [V] :
24
Rated Power [kW] :
4
Number of mounting bores :
3
Number of threaded holes :
0
Number of Teeth :
10
Clamp :
30
Clamp :
50
Clamp :
31
Flange Diameter [mm] :
89
Rotation Direction :
Clockwise rotation
Pinion Rest Position [mm] :
48
Starter Type :
Self-supporting
Bore Diameter [mm] :
10.9
Bore Diameter 2 [mm] :
10.9
Bore Ø 3 [mm] :
10.9
Length [mm] :
320
Position/Degree :
rechts
Mounting Angle [degrees] :
120
Jaw opening angle measurement [Degree] :
200
Mounting bore angle measurement [degree] :
120
- Vendor BOSCH
- SKU 0986020170
- IVECO : 2995986 42498718 4892338 5801381129 5801577135
- NISSAN : 23300LA4MA
- CASE IH : 4892338
- CUMMINS : 4 892 338 5 259 579 5 265 096
- BORG & BECK : BST32069
- BOSCH : 0 001 251 010
- BOSCH : 1 986 S10 040
- Carwood Group : BREF0320986020170
- Carwood Group : BREF032112498
- Carwood Group : BREF0321986S10040
- FEBI BILSTEIN : 48970
- HELLA : 8EA 012 586-521
- LUCAS : LRS02180
- MAHLE : MS 100
- VALEO : 203005
- VALEO : 203038
- VALEO : 438594
- VALEO : 438596
- VALEO : 458332
- WAI : 30123N
- BOSCH : 2017
