Bosch 0986021741 Starter Motor
Your selected vehicle
Regular price
£107.58
inc. VAT
Pay in 3 interest-free payments with Klarna
Standard delivery
Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.
The Bosch 0986021741 Starter Motor is a replacement starting or charging-system component that supports electrical power generation, storage or engine cranking in the vehicle. Its catalogue specification records 12 V electrical rating, 1.2 kW rated power, 12 teeth, and Self-supporting starter type. Match the reference, voltage, output or capacity, terminals, mounting and vehicle application before fitting; isolate the electrical system and follow the manufacturer's coding procedure where required.
Function :
Starter
Voltage [V] :
12
Rated Power [kW] :
1.2
Number of mounting bores :
2
Number of threaded holes :
2
Number of Teeth :
12
Clamp :
30
Flange Diameter [mm] :
65
Rotation Direction :
Clockwise rotation
Pinion Rest Position [mm] :
-1.56
Starter Type :
Self-supporting
Thread Size 1 :
M10x1.5
Thread Size 2 :
M10x1.5
Bore Diameter [mm] :
4
Length [mm] :
201
Position/Degree :
links
Mounting Angle [degrees] :
40
Jaw opening angle measurement [Degree] :
142
Mounting bore angle measurement [degree] :
40
Vehicle Equipment Line/Variant :
Standard
Vehicle Equipment Line/Variant :
Spezial
Construction Year from :
02.2003
Construction Year to :
05.2005
Construction Year from :
06.2005
Construction Year to :
09.2007
for OE number :
23300 00Q0H
- Vendor BOSCH
- SKU 0986021741
- APEC : ASM1050
- BLUE PRINT : ADN11272
- BORG & BECK : BST2037
- BOSCH : 1 986 S01 019
- Carwood Group : BREF0320986021741
- Carwood Group : BREF032113927
- Carwood Group : BREF0321986S01019
- FEBI BILSTEIN : 101621
- HELLA : 8EA 011 610-201
- LUCAS : LRS01593
- NAPA : NSM1050
- VALEO : 446524
- WAI : 32593N
- WAI : S133.907
- BOSCH : 2174
