Bosch 0986022800 Starter Motor
Your selected vehicle
Regular price
£118.52
inc. VAT
Pay in 3 interest-free payments with Klarna
Standard delivery
Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.
The Bosch 0986022800 Starter Motor is a replacement starting or charging-system component that supports electrical power generation, storage or engine cranking in the vehicle. Its catalogue specification records 12 V electrical rating, 1.4 kW rated power, 10, 13, and 12 teeth, and Self-supporting starter type. Match the reference, voltage, output or capacity, terminals, mounting and vehicle application before fitting; isolate the electrical system and follow the manufacturer's coding procedure where required.
Function :
Starter
Voltage [V] :
12
Rated Power [kW] :
1.4
Number of mounting bores :
3
Number of threaded holes :
3
Number of Teeth :
10
Number of Teeth :
13
Number of Teeth :
12
Clamp :
50
Flange Diameter [mm] :
66.5
Rotation Direction :
Clockwise rotation
Pinion Rest Position [mm] :
0.77
Starter Type :
Self-supporting
Thread Size :
M8
Thread Size 1 :
M10x1.5
Thread Size 2 :
M10x1.5
Length [mm] :
201
Position/Degree :
rechts
Mounting Angle [degrees] :
44
Jaw opening angle measurement [Degree] :
77
Mounting bore angle measurement [degree] :
44
Vehicle Equipment :
for vehicles with start-stop function
Emission Standard :
Euro 5
- Vendor BOSCH
- SKU 0986022800
- MERCEDES-BENZ : A 607 906 03 00 607 906 03 00
- NISSAN : 23300 BC400 23300BC40B 2330000QA0 2330000Q0F 2330000Q1H
- RENAULT : 23 30 006 03R 23 30 031 52R 23 30 033 29R 77 11 135 334 82 00 251 007 82 00 285 128 82 00 306 595 82 00 399 594 82 00 584 675 82 00 584 843 82 00 836 473
- DACIA : 23 30 006 03R 23 30 031 52R 23 30 033 29R 82 00 306 595 82 00 584 675 82 00 836 473
- BOSCH : 2280
