Home / Car Parts / Electrical / Starter System / Starter Motors
Bosch 0986023880 Starter - 1
Bosch 0986023880 Starter - 1
BOSCH

Bosch 0986023880 Starter Motor

5.0/5 60 AutoMotoPart customer reviews Verified reviews across our products & service
SKU: 0986023880

Check product compatibility

Enter your registration or select your vehicle to check this product fits.

In stock
Orders placed by 17:00 are usually dispatched the same working day
£165.17 inc. VAT
Pay in 3 interest-free payments with Klarna
Free UK mainland standard delivery 14-day returns

Need help choosing the right part? Call 01472 869 066

CHEVROLET
AVEO / KALOS Hatchback (T200)
Description Cylinder Capacity Horse Power Year
1.2 1150 CCM 72 HP 01/2004 - 05/2008
AVEO / KALOS Saloon (T250, T255)
Description Cylinder Capacity Horse Power Year
1.2 1206 CCM 84 HP From 01/2008
1.2 1206 CCM 75 HP From 01/2008
1.2 1150 CCM 72 HP 03/2005 - 12/2007
1.2 LPG 1206 CCM 84 HP From 01/2009
AVEO / KALOS Hatchback (T250, T255)
Description Cylinder Capacity Horse Power Year
1.2 1206 CCM 84 HP From 04/2008
1.2 LPG 1206 CCM 84 HP 04/2008 - 12/2011
MATIZ (M200, M250)
Description Cylinder Capacity Horse Power Year
1.0 LPG 995 CCM 67 HP 03/2005 - 03/2011
1.0 995 CCM 65 HP From 01/2007
1.0 995 CCM 64 HP 03/2005 - 12/2007
1.0 995 CCM 67 HP From 03/2005
1.0 995 CCM 62 HP 01/2008 - 12/2013
SPARK
Description Cylinder Capacity Horse Power Year
1.0 SX 995 CCM 63 HP From 05/2005
SPARK (M300)
Description Cylinder Capacity Horse Power Year
1.0 995 CCM 68 HP From 03/2010
1.2 1206 CCM 82 HP From 03/2010
1.2 LPG 1206 CCM 82 HP From 03/2010
1.0 LPG 995 CCM 68 HP From 03/2010
DAEWOO
KALOS (KLAS)
Description Cylinder Capacity Horse Power Year
1.2 1150 CCM 72 HP From 04/2003
MATIZ (M100, M150)
Description Cylinder Capacity Horse Power Year
1.0 995 CCM 64 HP From 01/2003
1.0 995 CCM 63 HP 04/2003 - 12/2004

The Bosch 0986023880 Starter Motor is a replacement starting or charging-system component that supports electrical power generation, storage or engine cranking in the vehicle. Its catalogue specification records 12 V electrical rating, 2 kW rated power, 8 teeth, and Self-supporting starter type. Match the reference, voltage, output or capacity, terminals, mounting and vehicle application before fitting; isolate the electrical system and follow the manufacturer's coding procedure where required.

Function : Starter
Voltage [V] : 12
Rated Power [kW] : 2
Number of mounting bores : 2
Number of threaded holes : 1
Number of Teeth : 8
Clamp : 30
Flange Diameter [mm] : 75
Rotation Direction : Clockwise rotation
Pinion Rest Position [mm] : 7.46
Starter Type : Self-supporting
Thread Size : M8
Bore Diameter 2 [mm] : 8.5
Length [mm] : 184
Position/Degree : rechts
Mounting Angle [degrees] : 30
Jaw opening angle measurement [Degree] : 80
Mounting bore angle measurement [degree] : 30
Engine Code : LY4
Construction Year from : 02.2005
Construction Year to : 04.2008
Engine Code : B12S1
Engine Code : F12S3
Construction Year from : 04.2008
Construction Year to : 12.2011
  • Vendor BOSCH
  • SKU 0986023880
  • Barcode 4047024813663
  • CHEVROLET : 25 187 951 96 289 430 96 469 962 96 497 702 96 943 429 96 963 483
  • DAEWOO : 96289430 96497702
  • APEC : ASM1616
  • BORG & BECK : BST2570
  • BOSCH : 1 986 S01 029
  • Carwood Group : BREF0320986023880
  • Carwood Group : BREF032113860
  • FEBI BILSTEIN : 187775
  • HELLA : 8EA 012 528-401
  • LUCAS : LRS02246
  • NAPA : NSM1616
  • VALEO : 446534
  • WAI : 33246N
  • WAI : S131.577
  • BOSCH : 2388
