Bosch 0986025870 Starter Motor
Your selected vehicle
Regular price
£243.26
inc. VAT
Pay in 3 interest-free payments with Klarna
Standard delivery
Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.
The Bosch 0986025870 Starter Motor is a replacement starting or charging-system component that supports electrical power generation, storage or engine cranking in the vehicle. Its catalogue specification records 12 V electrical rating, 1.5 kW rated power, Floating pinion starter type, and manual Transmission transmission. Match the reference, voltage, output or capacity, terminals, mounting and vehicle application before fitting; isolate the electrical system and follow the manufacturer's coding procedure where required.
Function :
Starter
Voltage [V] :
12
Rated Power [kW] :
1.5
Number of mounting bores :
3
Number of threaded holes :
0
Number of Teeth :
13
Clamp :
30
Flange Diameter [mm] :
79
Rotation Direction :
Anticlockwise rotation
Pinion Rest Position [mm] :
61.6
Starter Type :
Floating pinion
Bore Diameter [mm] :
12.5
Bore Diameter 2 [mm] :
12.5
Bore Ø 3 [mm] :
12.5
Length [mm] :
225
Position/Degree :
links
Mounting Angle [degrees] :
43
Mounting bore angle measurement [degree] :
43
Engine Code :
DLAC
Transmission Type :
Manual Transmission
- Vendor BOSCH
- SKU 0986025870
- BOSCH : 2587
