Bosch 0986478314 Brake Disc

Position: Front
5.0/5 78 reviews
SKU: 0986478314

Check product compatibility

Enter your registration or select your vehicle to check this product fits.

Only 2 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
Regular price £81.03 inc. VAT

Complete the job

Pay in 3 interest-free payments with Klarna

Available at checkout. Subject to eligibility.

Free standard delivery to UK mainland

Delivery estimate confirmed at checkout. Delivery details
Pay securely with
  • Visa
  • Mastercard
  • Apple Pay
  • PayPal
  • Klarna
  • Google Pay

Need help with fitment? 01472 869 066

Spend & Earn

Earn 2% store credit on eligible parts spend. Available 30 days after fulfilment. Sign in at checkout to use your balance.

Excludes VAT, delivery, discounts and amounts paid with store credit.

MG
MG 6 Saloon
Description Cylinder Capacity Horse Power Year
1.8 1795 CCM 133 HP From 11/2010
1.8 T 1796 CCM 160 HP From 11/2010
1.9 DTi 1849 CCM 150 HP From 08/2012
MG 6 Hatchback
Description Cylinder Capacity Horse Power Year
1.8 T 1796 CCM 160 HP From 11/2010
1.8 1795 CCM 133 HP From 11/2010
1.9 DTi 1849 CCM 150 HP From 08/2012
ZT
Description Cylinder Capacity Horse Power Year
190 2497 CCM 190 HP 06/2001 - 07/2005
160 2497 CCM 160 HP 06/2001 - 07/2005
2.0 CDTi 1951 CCM 131 HP 11/2002 - 07/2005
1.8 16V 1795 CCM 120 HP 01/2003 - 07/2005
1.8 T 16V 1796 CCM 160 HP 01/2003 - 07/2005
180 2497 CCM 177 HP 02/2002 - 10/2005
2.0 CDTi 1951 CCM 116 HP 06/2002 - 09/2003
ZT- T
Description Cylinder Capacity Horse Power Year
160 2497 CCM 160 HP 10/2001 - 07/2005
190 2497 CCM 190 HP 10/2001 - 07/2005
2.0 CDTi 1951 CCM 131 HP 11/2002 - 07/2005
1.8 16V 1795 CCM 120 HP 01/2003 - 07/2005
1.8 T 16V 1796 CCM 160 HP 01/2003 - 07/2005
180 2497 CCM 177 HP 02/2002 - 10/2005
2.0 CDTi 1951 CCM 116 HP 06/2002 - 07/2005
ROVER
75 (RJ)
Description Cylinder Capacity Horse Power Year
1.8 1796 CCM 120 HP 02/1999 - 05/2005
2.0 V6 1997 CCM 150 HP 02/1999 - 05/2005
2.5 V6 2497 CCM 175 HP 02/1999 - 10/2001
2.0 CDT 1951 CCM 115 HP 02/1999 - 05/2005
2.5 V6 2497 CCM 177 HP 10/2001 - 05/2005
2.0 CDTi 1951 CCM 131 HP 02/2003 - 04/2005
1.8 Turbo 1796 CCM 150 HP 05/2003 - 05/2005
75 I Tourer (RJ)
Description Cylinder Capacity Horse Power Year
1.8 1796 CCM 120 HP 08/2001 - 05/2005
2.0 V6 1997 CCM 150 HP 08/2001 - 05/2005
2.5 V6 2497 CCM 177 HP 08/2001 - 05/2005
2.0 CDT 1951 CCM 115 HP 08/2001 - 05/2005
2.0 CDTi 1951 CCM 131 HP 02/2003 - 05/2005
1.8 Turbo 1796 CCM 150 HP 05/2003 - 05/2005

The Bosch 0986478314 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records 283.7 mm outer diameter, 22 mm brake disc thickness, 19 mm minimum thickness, and vented disc construction. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Outer Diameter [mm] : 283.7
Brake Disc Thickness [mm] : 22
Minimum thickness [mm] : 19
Height [mm] : 38.2
Bolt Hole Circle Ø [mm] : 100
Brake Disc Type : Vented
Centering Diameter [mm] : 64.15
Number of Holes : 5
Surface : Oiled
fulfils ECE standard : ECE-R90
Bore Diameter up to [mm] : 15.1
  • Vendor BOSCH
  • SKU 0986478314
  • Barcode 4047024560000
  • MG : SDB000810 SDB100940
  • ROVER : GBD 90844 SDB 0008 10 SDB 0008 80 SDB 1009 40
  • APEC : DSK835
  • APEC : SDK6157
  • BLUE PRINT : ADG043235
  • BORG & BECK : BBD4130
  • BREMBO : 09.7879.10
  • BREMBO : 09.7879.11
  • DELPHI : BG3503
  • Fahren : FBD6157
  • FEBI BILSTEIN : 17963
  • HELLA : 8DD 355 107-251
  • MINTEX : MDC1067
  • NAPA : NBD5904
  • National : NBD965
  • SKF : VKBD 80349 V2
  • TEXTAR : 92103400
  • TRW : DF4202
  • VALEO : 186814
  • VALEO : 673680
  • BOSCH : BD257
  • BOSCH : E1 90R-02C0411/1445
