Bosch 0986478712 Brake Disc
Your selected vehicle
Regular price
£22.68
inc. VAT
Pay in 3 interest-free payments with Klarna
Standard delivery
Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.
The Bosch 0986478712 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records 236 mm outer diameter, 12.5 mm brake disc thickness, 9.7 mm minimum thickness, and solid disc construction. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.
Function :
Brake Disc
Outer Diameter [mm] :
236
Brake Disc Thickness [mm] :
12.5
Minimum thickness [mm] :
9.7
Height [mm] :
35.3
Bolt Hole Circle Ø [mm] :
102
Brake Disc Type :
solid
Centering Diameter [mm] :
86.02
Number of Holes :
4
Surface :
Oiled
fulfils ECE standard :
ECE-R90
- Vendor BOSCH
- SKU 0986478712
- CHRYSLER : 96455 424
- CHEVROLET : 96 455 424
- DAEWOO : 96284392 96320531 96455424
- APEC : DSK301
- APEC : SDK6205
- BLUE PRINT : ADG04322
- BORG & BECK : BBD4136
- BREMBO : 08.7822.10
- DELPHI : BG3551
- Fahren : FBD6205
- FEBI BILSTEIN : 17509
- FTE : 9072594
- FTE : 9082407
- HELLA : 8DD 355 107-011
- MEYLE : 29-15 521 0001
- MINTEX : MDC1459
- NAPA : NBD5544
- National : NBD981
- SKF : VKBD 80600 S2
- TEXTAR : 92100303
- TRW : DF4123
- VALEO : 186742
- BOSCH : BD626
