BOSCH

Bosch 0986479411 Brake Disc

SKU: 0986479411

Your selected vehicle

Only 4 left

Low inventory - Hurry! — Order by 17:00 for same-day dispatch

£74.52 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

MERCEDES-BENZ

C-CLASS (W204)

Description	Cylinder Capacity	Horse Power	Year
C 250 CDI 4-matic (204.082)	2143 CCM	204 HP	01/2011 - 01/2014
C 300 CDI 4-matic (204.092)	2987 CCM	231 HP	01/2011 - 01/2014
C 350 (204.057)	3498 CCM	306 HP	01/2011 - 01/2014
C 350 4-matic (204.088)	3498 CCM	306 HP	01/2011 - 01/2014
C 350 CDI (204.023)	2987 CCM	265 HP	06/2011 - 01/2014
C 320 CDI (204.022)	2987 CCM	224 HP	01/2007 - 01/2014

C-CLASS T-Model (S204)

Description	Cylinder Capacity	Horse Power	Year
C 250 CDI 4-matic (204.282)	2143 CCM	204 HP	04/2010 - 08/2014
C 350 CDI (204.223)	2987 CCM	265 HP	06/2011 - 08/2014
C 350 CGI (204.257)	3498 CCM	306 HP	06/2011 - 08/2014
C 350 (204.256)	3498 CCM	272 HP	08/2007 - 08/2014

C-CLASS Coupe (C204)

Description	Cylinder Capacity	Horse Power	Year
C 250 CDI (204.303)	2143 CCM	204 HP	From 06/2011
C 180 (204.349)	1796 CCM	156 HP	From 06/2011
C 250 (204.347)	1796 CCM	204 HP	From 06/2011
C 350 (204.357)	3498 CCM	306 HP	From 06/2011
C 200 CGI (204.348)	1796 CCM	184 HP	From 06/2011

E-CLASS Coupe (C207)

Description	Cylinder Capacity	Horse Power	Year
E 350 CDI (207.323)	2987 CCM	265 HP	06/2011 - 06/2013
E 300 (207.355)	3498 CCM	252 HP	04/2011 - 06/2016
E 500 (207.373)	4663 CCM	408 HP	09/2011 - 12/2016
E 350 CGI (207.357)	3498 CCM	292 HP	01/2009 - 12/2011
E 500 (207.372)	5461 CCM	388 HP	01/2009 - 12/2016
E 350 CDI (207.322)	2987 CCM	231 HP	01/2009 - 06/2011
E 400 (207.365)	2996 CCM	333 HP	06/2013 - 12/2016
E 350 BlueTEC (207.326)	2987 CCM	252 HP	06/2013 - 12/2016

E-CLASS Convertible (A207)

Description	Cylinder Capacity	Horse Power	Year
E 350 CDI (207.423)	2987 CCM	265 HP	04/2011 - 12/2013
E 300 (207.455)	3498 CCM	252 HP	04/2011 - 12/2016
E 500 (207.473)	4663 CCM	408 HP	09/2011 - 12/2016
E 350 CDI (207.422)	2987 CCM	231 HP	01/2010 - 12/2011
E 350 CGI (207.457)	3498 CCM	292 HP	01/2010 - 12/2014
E 500 (207.472)	5461 CCM	388 HP	01/2010 - 12/2011
E 350 BlueTEC (207.426)	2987 CCM	252 HP	06/2013 - 12/2016

The Bosch 0986479411 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records 300 mm outer diameter, 22 mm brake disc thickness, 19.4 mm minimum thickness, and vented disc construction. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc

Outer Diameter [mm] : 300

Brake Disc Thickness [mm] : 22

Minimum thickness [mm] : 19.4

Height [mm] : 57.6

Bolt Hole Circle Ø [mm] : 112

Brake Disc Type : Vented

Centering Diameter [mm] : 67

Number of Holes : 5

Surface : Coated

Machining : Alloyed/High-carbon

fulfils ECE standard : ECE-R90

Bore Diameter up to [mm] : 15.3

APEC : DSK2613
APEC : SDK6557
BLUE PRINT : ADU174305
BORG & BECK : BBD4703
BREMBO : 09.A760.10
BREMBO : 09.A760.11
BREMBO : 09.A760.1X
DELPHI : BG4226C
Fahren : FBD6557
FEBI BILSTEIN : 43838
FTE : 9082292
FTE : 9082606
HELLA : 8DD 355 118-941
HELLA : 8DD 355 129-531
MEYLE : 015 523 0033/PD
MINTEX : MDC2051
NAPA : NBD5281
National : NBD1754
SKF : VKBD 90204 V1
TEXTAR : 92163605
TRW : DF4864S
VALEO : 197730
VALEO : 673397

Bosch 0986479411 Brake Disc
