BOSCH

Bosch 0986479691 Brake Disc

SKU: 0986479691
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£53.82 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

VOLVO
V40 Hatchback (525)
Description Cylinder Capacity Horse Power Year
T4 1984 CCM 180 HP 07/2013 - 12/2015
T3 GTDi 1596 CCM 150 HP 03/2012 - 12/2016
T4 GTDi 1596 CCM 180 HP 03/2012 - 12/2016
D2 1560 CCM 114 HP 03/2012 - 12/2016
D3 1984 CCM 150 HP 03/2012 - 03/2015
D4 1984 CCM 177 HP 03/2012 - 12/2014
T5 2497 CCM 254 HP 12/2012 - 12/2014
T5 1984 CCM 214 HP 03/2013 - 12/2015
T2 GTDi 1596 CCM 120 HP 04/2013 - 12/2016
D4 1969 CCM 190 HP 05/2014 - 08/2019
T5 1969 CCM 245 HP 05/2014 - 08/2019
T4 1596 CCM 200 HP 04/2014 - 12/2015
T2 1969 CCM 122 HP 02/2015 - 08/2019
T3 1969 CCM 152 HP 02/2015 - 08/2019
D2 1969 CCM 120 HP 02/2015 - 08/2019
V40 Cross Country (526)
Description Cylinder Capacity Horse Power Year
T4 AWD 1984 CCM 180 HP 07/2013 - 12/2015
T5 AWD 1984 CCM 214 HP 03/2013 - 12/2015
T5 AWD 2497 CCM 254 HP 10/2012 - 12/2016
T5 AWD 1969 CCM 245 HP 05/2014 - 08/2019
T4 AWD 1969 CCM 190 HP 05/2014 - 08/2019
T5 Polestar AWD 1969 CCM 253 HP 01/2015 - 08/2019
D4 1969 CCM 190 HP 05/2014 - 08/2019
T3 1969 CCM 152 HP 02/2015 - 08/2019
D2 1969 CCM 120 HP 02/2015 - 08/2019
T3 1498 CCM 152 HP 04/2015 - 08/2019
D3 1969 CCM 150 HP 04/2015 - 08/2019
T4 1984 CCM 180 HP 10/2013 - 12/2015
T4 GTDi 1596 CCM 180 HP 10/2012 - 12/2016
D2 1560 CCM 114 HP 10/2012 - 12/2016
D3 1984 CCM 150 HP 10/2012 - 03/2015

The Bosch 0986479691 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records 280 mm outer diameter, 11 mm brake disc thickness, 9 mm minimum thickness, and solid disc construction. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Outer Diameter [mm] : 280
Brake Disc Thickness [mm] : 11
Minimum thickness [mm] : 9
Height [mm] : 40.9
Bolt Hole Circle Ø [mm] : 108
Brake Disc Type : solid
Centering Diameter [mm] : 63.5
Number of Holes : 5
Surface : Coated
fulfils ECE standard : ECE-R90
Bore Diameter up to [mm] : 13.8
  • Vendor BOSCH
  • SKU 0986479691
  • Barcode 4047025167925
  • VOLVO : 31341645 31341646 31471039
  • APEC : DSK2983
  • APEC : SDK6741
  • BLUE PRINT : ADF124360
  • BORG & BECK : BBD4453
  • BORG & BECK : BBD5306
  • BREMBO : 08.9975.10
  • BREMBO : 08.9975.11
  • BREMBO : 08.9975.1X
  • BREMBO : 08.9975.75
  • DELPHI : BG3897C
  • Fahren : FBD6741
  • FEBI BILSTEIN : 105714
  • FTE : 9072397
  • HELLA : 8DD 355 119-501
  • MEYLE : 515 523 0008
  • MEYLE : 515 523 0008/PD
  • MINTEX : MDC2529C
  • NAPA : NBD5356
  • National : NBD2011
  • SKF : VKBD 91118 S2
  • TEXTAR : 92255603
  • TRW : DF6535
  • VALEO : 673188
  • BOSCH : BD1683
  • BOSCH : E1 90 R -02C0371/0083
