BOSCH

Bosch 0986479792 Brake Disc

SKU: 0986479792

Your selected vehicle

Only 1 left

Low inventory - Hurry! — Order by 17:00 for same-day dispatch

£64.46 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

SUZUKI

SWIFT III (FZ, NZ)

Description	Cylinder Capacity	Horse Power	Year
1.2 (AZH412, ZC72S)	1242 CCM	94 HP	10/2010 - 04/2017
1.3 DDiS (AZG413D, ZC02S, ZC92S)	1248 CCM	75 HP	10/2010 - 04/2017
1.2 (AZG412, ZC72S)	1242 CCM	90 HP	10/2010 - 04/2017
1.2 4x4 (AZG412, ZD72S)	1242 CCM	90 HP	10/2010 - 04/2017
1.2 (AZH412, AZG412, ZC72S)	1242 CCM	91 HP	08/2012 - 04/2017
1.2 4WD (AZH412, AZG412, ZD72S)	1242 CCM	91 HP	08/2012 - 04/2017

The Bosch 0986479792 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records 259.2 mm outer diameter, 9 mm brake disc thickness, 8 mm minimum thickness, and solid disc construction. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc

Outer Diameter [mm] : 259.2

Brake Disc Thickness [mm] : 9

Minimum thickness [mm] : 8

Height [mm] : 43.2

Bolt Hole Circle Ø [mm] : 100

Brake Disc Type : solid

Centering Diameter [mm] : 62

Number of Holes : 4

Surface : Oiled

Machining : High-carbon

fulfils ECE standard : ECE-R90

Bore Diameter up to [mm] : 14.1

BLUE PRINT : ADK84339
BORG & BECK : BBD5209
BREMBO : 08.C046.31
DELPHI : BG4345
FEBI BILSTEIN : 108531
FTE : 9072834
FTE : 9082298
HELLA : 8DD 355 117-301
MEYLE : 33-15 523 0003/PD
MINTEX : MDC2267
National : NBD1806
SKF : VKBD 90265 S2
TEXTAR : 92231403
TRW : DF6122

Bosch 0986479792 Brake Disc
