BOSCH

Bosch 0986479A96 Brake Disc

5.0/5 71 reviews
SKU: 0986479A96

Check product compatibility

Enter your registration or select your vehicle to check this product fits.

Only 2 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£87.59 inc. VAT

Complete the job

APEC — Aerosol Brake cleaner 600ml
£6.92

Pay in 3 interest-free payments with Klarna

Available at checkout. Subject to eligibility.

Free standard delivery to UK mainland

Delivery estimate confirmed at checkout. Delivery details
Pay securely with
  • Visa
  • Mastercard
  • Apple Pay
  • PayPal
  • Klarna
  • Google Pay

Need help with fitment? 01472 869 066

TOYOTA
HILUX VIGO VII Pickup (_N1_, _N2_, _N3_)
Description Cylinder Capacity Horse Power Year
2.5 D-4D (KUN15, KUN35) 2494 CCM 144 HP 01/2010 - 05/2015
2.5 D 4WD (KUN25) 2494 CCM 102 HP 03/2005 - 05/2015
3.0 D-4D 4WD (KUN26) 2982 CCM 171 HP 08/2005 - 09/2015
3.0 D-4D 4WD (KUN26) 2982 CCM 163 HP 03/2005 - 05/2015
2.5 D-4D 4WD (KUN25) 2494 CCM 144 HP 12/2007 - 05/2015
2.5 D-4D 4WD (KUN25_) 2494 CCM 128 HP 11/2004 - 12/2005
3.0 D-4D 4WD (KUN26) 2982 CCM 169 HP 08/2005 - 05/2015
HILUX VII Platform/Chassis (_N1_, _N2_)
Description Cylinder Capacity Horse Power Year
3.0 D 4WD (KUN26) 2982 CCM 171 HP From 02/2005
HILUX VIII Pickup (_N1_)
Description Cylinder Capacity Horse Power Year
2.4 D 4WD (GUN125) 2393 CCM 170 HP From 10/2018

The Bosch 0986479A96 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records 297.2 mm outer diameter, 25 mm brake disc thickness, 23 mm minimum thickness, and vented disc construction. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Outer Diameter [mm] : 297.2
Brake Disc Thickness [mm] : 25
Minimum thickness [mm] : 23
Height [mm] : 67.4
Bolt Hole Circle Ø [mm] : 139.7
Brake Disc Type : Vented
Centering Diameter [mm] : 108
Number of Holes : 6
Surface : Oiled
fulfils ECE standard : ECE-R90
Bore Diameter up to [mm] : 14.4
  • Vendor BOSCH
  • SKU 0986479A96
  • Barcode 4047025362993
  • TOYOTA : 435120K060 435120K070 435120K080
  • APEC : DSK2782
  • APEC : SDK6636
  • BLUE PRINT : ADT343211
  • BORG & BECK : BBD4815
  • BREMBO : 09.A634.10
  • BREMBO : 09.A634.11
  • BREMBO : 09.A634.1S
  • BREMBO : 09.A634.1X
  • DELPHI : BG4211C
  • Fahren : FBD6636
  • FEBI BILSTEIN : 108399
  • FTE : 9072417
  • FTE : 9082520
  • HELLA : 8DD 355 116-821
  • MEYLE : 30-15 521 0126
  • MINTEX : MDC2184
  • NAPA : NBD5284
  • SKF : VKBD 80346 V2
  • TEXTAR : 92222600
  • TRW : DF4917
  • VALEO : 673311
  • BOSCH : BD 2156
