BOSCH

Bosch 0986479D49 Brake Disc

SKU: 0986479D49

Your selected vehicle

Only 1 left

Low inventory - Hurry! — Order by 17:00 for same-day dispatch

£36.97 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

SAAB

9-5 (YS3E)

Description	Cylinder Capacity	Horse Power	Year
2.0 t	1985 CCM	150 HP	09/1997 - 12/2009
2.3 t	2290 CCM	170 HP	09/1997 - 12/2003
3.0 V6t	2962 CCM	200 HP	01/1998 - 08/2005
2.3 Turbo	2290 CCM	230 HP	10/1999 - 09/2001
2.3 t	2290 CCM	185 HP	01/2001 - 12/2009
3.0 TiD	2958 CCM	177 HP	07/2001 - 08/2005
2.3 Turbo	2290 CCM	250 HP	09/2001 - 12/2009
2.3 Turbo	2290 CCM	220 HP	07/2003 - 12/2009
2.3 Turbo	2290 CCM	260 HP	11/2005 - 12/2009
2.0 t Biopower	1985 CCM	179 HP	09/2005 - 12/2009
2.0 t	1985 CCM	185 HP	07/2000 - 12/2009
2.3 Turbo	2290 CCM	305 HP	06/2003 - 08/2005

9-5 Estate (YS3E)

Description	Cylinder Capacity	Horse Power	Year
2.0 t	1985 CCM	150 HP	10/1998 - 12/2009
3.0 V6t	2962 CCM	200 HP	10/1998 - 08/2005
2.3 Turbo	2290 CCM	230 HP	10/1999 - 09/2001
2.3 t	2290 CCM	185 HP	09/1999 - 01/2008
3.0 TiD	2958 CCM	177 HP	07/2001 - 08/2005
2.3 Turbo	2290 CCM	250 HP	09/2001 - 12/2009
2.3 Turbo	2290 CCM	220 HP	07/2003 - 12/2009
2.3 Turbo	2290 CCM	260 HP	01/2006 - 12/2009
2.0 t Biopower	1985 CCM	179 HP	09/2005 - 12/2009
2.0 t	1985 CCM	185 HP	07/2000 - 07/2001
2.3 t BioPower	2290 CCM	207 HP	11/2006 - 12/2009

The Bosch 0986479D49 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records 300 mm outer diameter, 20 mm brake disc thickness, 18 mm minimum thickness, and vented disc construction. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc

Outer Diameter [mm] : 300

Brake Disc Thickness [mm] : 20

Minimum thickness [mm] : 18

Height [mm] : 69.1

Bolt Hole Circle Ø [mm] : 110

Brake Disc Type : Vented

Centering Diameter [mm] : 65.6

Number of Holes : 5

Surface : Coated

fulfils ECE standard : ECE-R90

Bore Diameter up to [mm] : 14.2

APEC : DSK2419
BLUE PRINT : ADBP430125
BORG & BECK : BBD4558
BREMBO : 09.B507.10
BREMBO : 09.B507.11
DELPHI : BG4046
FEBI BILSTEIN : 43812
FTE : 9072504
FTE : 9082734
HELLA : 8DD 355 114-381
MEYLE : 815 523 5026
MINTEX : MDC1841
TEXTAR : 92164900
TRW : DF4337
VALEO : 673464
