BOSCH

Bosch 0986479D79 Brake Disc

SKU: 0986479D79
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£82.02 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

JAGUAR
E-PACE (X540)
Description Cylinder Capacity Horse Power Year
2.0 P200 AWD 1997 CCM 249 HP From 09/2017
2.0 AWD 1997 CCM 300 HP From 09/2017
2.0 D150 1999 CCM 150 HP From 09/2017
2.0 D150 AWD 1999 CCM 150 HP From 09/2017
2.0 D180 AWD 1999 CCM 179 HP From 09/2017
2.0 P200 AWD 1997 CCM 200 HP From 08/2018
LAND ROVER
DISCOVERY SPORT (L550)
Description Cylinder Capacity Horse Power Year
2.0 D 4x4 1999 CCM 150 HP From 12/2014
2.2 D 4x4 2179 CCM 150 HP From 09/2014
2.2 D 4x4 2179 CCM 190 HP From 09/2014
2.0 4x4 1999 CCM 241 HP From 11/2014
2.0 D 4x4 1999 CCM 180 HP From 06/2015
2.0 D 1999 CCM 150 HP From 08/2015
2.0 4x4 1997 CCM 290 HP From 08/2017
2.0 D 4x4 1999 CCM 241 HP From 08/2017
2.0 Si4 FLEX 4x4 1997 CCM 241 HP From 12/2018
RANGE ROVER EVOQUE (L538)
Description Cylinder Capacity Horse Power Year
2.2 D 2179 CCM 150 HP 06/2011 - 12/2019
2.0 4x4 1999 CCM 241 HP 06/2011 - 12/2019
2.0 4x4 1999 CCM 240 HP 09/2011 - 12/2019
2.0 D 4x4 1999 CCM 150 HP 06/2015 - 12/2019
2.0 D 4x4 1999 CCM 180 HP 05/2015 - 12/2019
2.0 4x4 1997 CCM 241 HP 08/2017 - 12/2019
RANGE ROVER EVOQUE VAN (L538)
Description Cylinder Capacity Horse Power Year
TD4 2179 CCM 150 HP 05/2015 - 12/2019
RANGE ROVER EVOQUE Convertible (L538)
Description Cylinder Capacity Horse Power Year
2.0 D 4x4 1999 CCM 150 HP 11/2015 - 12/2019
2.0 D 4x4 1999 CCM 180 HP 11/2015 - 12/2019
2.0 4x4 1999 CCM 241 HP 11/2015 - 12/2019
2.0 D 4x4 1999 CCM 241 HP 08/2017 - 12/2019
2.0 4x4 1997 CCM 241 HP 08/2017 - 12/2019

The Bosch 0986479D79 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records 325 mm outer diameter, 30 mm brake disc thickness, 28 mm minimum thickness, and vented disc construction. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Outer Diameter [mm] : 325
Brake Disc Thickness [mm] : 30
Minimum thickness [mm] : 28
Height [mm] : 52
Bolt Hole Circle Ø [mm] : 107.9
Brake Disc Type : Vented
Centering Diameter [mm] : 63.5
Number of Holes : 5
Surface : Coated
Machining : High-carbon
Bore Diameter up to [mm] : 15.8
  • Vendor BOSCH
  • SKU 0986479D79
  • Barcode 4047026143171
  • ROVER : J9C 2136 LR059122
  • LAND ROVER : J9C2136 LR059122
  • APEC : DSK3117
  • APEC : SDK6807
  • BLUE PRINT : ADJ134365
  • BORG & BECK : BBD6086S
  • BREMBO : 09.C207.11
  • BREMBO : 09.C207.1X
  • DELPHI : BG9183C
  • Fahren : FBD6807
  • FEBI BILSTEIN : 108638
  • FTE : 9081350
  • HELLA : 8DD 355 123-111
  • MEYLE : 53-83 521 0019/PD
  • MINTEX : MDC3014C
  • NAPA : NBD5664
  • SKF : VKBD 81100 V1
  • TEXTAR : 92278603
  • TEXTAR : 92278605
  • TRW : DF6515S
  • TRW : DF6848S
  • VALEO : 673087
  • BOSCH : BD2565
