BOSCH

Bosch 0986479E55 Brake Disc

SKU: 0986479E55

Your selected vehicle

Only 1 left

Low inventory - Hurry! — Order by 17:00 for same-day dispatch

£27.40 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

MAZDA

CX-3 (DK)

Description	Cylinder Capacity	Horse Power	Year
1.5 SKYACTIV-D (DK2WS, DK5FW)	1499 CCM	105 HP	02/2015 - 01/2018
1.5 SKYACTIV-D AWD (DK4WS, DK5AW)	1499 CCM	105 HP	02/2015 - 01/2018
2.0 SKYACTIV-G (DK5W, DK6W)	1998 CCM	120 HP	From 05/2015
2.0 SKYACTIV-G AWD (DK4W7, DKEAW)	1998 CCM	150 HP	From 05/2015

The Bosch 0986479E55 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records 281 mm outer diameter, 9.5 mm brake disc thickness, 7.5 mm minimum thickness, and solid disc construction. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc

Outer Diameter [mm] : 281

Brake Disc Thickness [mm] : 9.5

Minimum thickness [mm] : 7.5

Height [mm] : 35.7

Bolt Hole Circle Ø [mm] : 114.3

Brake Disc Type : solid

Centering Diameter [mm] : 68

Number of Holes : 5

Surface : Coated

Supplementary Article/Supplementary Info 2 : with bolts/screws

fulfils ECE standard : ECE-R90

Bore Diameter up to [mm] : 13.3

APEC : DSK3309
APEC : SDK7014
BLUE PRINT : ADM543132
BORG & BECK : BBD5567
BREMBO : 08.D222.11
DELPHI : BG4959C
FEBI BILSTEIN : 108666
FTE : 9082630
HELLA : 8DD 355 126-711
MINTEX : MDC2821C
NAPA : NBD5857
National : NBD2098
TEXTAR : 92293703
TRW : DF6807

Bosch 0986479E55 Brake Disc
