BOSCH

Bosch 0986487568 Brake Shoe Set

5.0/5 71 reviews
SKU: 0986487568

Check product compatibility

Enter your registration or select your vehicle to check this product fits.

Only 2 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£17.78 inc. VAT

Pay in 3 interest-free payments with Klarna

Available at checkout. Subject to eligibility.

Free standard delivery to UK mainland

Delivery estimate confirmed at checkout. Delivery details
Pay securely with
  • Visa
  • Mastercard
  • Apple Pay
  • PayPal
  • Klarna
  • Google Pay

Need help with fitment? 01472 869 066

Spend & Earn

Earn 2% store credit on eligible parts spend. Available 30 days after fulfilment. Sign in at checkout to use your balance.

Excludes VAT, delivery, discounts and amounts paid with store credit.

PEUGEOT
206 Hatchback (2A/C)
Description Cylinder Capacity Horse Power Year
1.1 i 1124 CCM 60 HP 09/1998 - 02/2007
1.4 i 1360 CCM 75 HP 09/1998 - 12/2012
1.6 i 1587 CCM 89 HP 09/1998 - 12/2000
1.9 D 1868 CCM 69 HP 09/1998 - 11/2001
1.4 HDi eco 70 1398 CCM 68 HP 09/2001 - 04/2009
1.1 1124 CCM 54 HP 08/1998 - 07/2000
1.4 HDi 1398 CCM 69 HP 09/2002 - 02/2007
206 Van
Description Cylinder Capacity Horse Power Year
1.4 HDi 1398 CCM 68 HP 09/2001 - 03/2009
1.9 D 1868 CCM 69 HP 04/1999 - 05/2007
206 SW (2E/K)
Description Cylinder Capacity Horse Power Year
1.4 1360 CCM 75 HP 07/2002 - 02/2007
206 Saloon
Description Cylinder Capacity Horse Power Year
1.4 1360 CCM 75 HP From 03/2007
1.4 HDi eco 70 1398 CCM 68 HP From 09/2008
206+ (2L_, 2M_)
Description Cylinder Capacity Horse Power Year
1.4 i 1360 CCM 73 HP 09/2010 - 06/2013
1.1 1124 CCM 60 HP 01/2009 - 06/2013
1.4 i (2LKFWA, 2MKFWA) 1360 CCM 75 HP 01/2009 - 08/2013
1.4 HDi eco 70 1398 CCM 68 HP 01/2009 - 06/2013

The Bosch 0986487568 Brake Shoe Set is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records 180 mm inner brake drum diameter, 32 mm width, with lining brake lining, and rear axle fitting position. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Shoe Set
Inner brake drum diameter [mm] : 180
Width [mm] : 32
Brake Lining : with lining
Engine Code : HFX (TU1A)
Engine Code : HFV<TU1AE5>
Construction Year from : 03.2009
Construction Year to : 05.2013
Fitting Position : Rear Axle
Braking/Driving Dynamics : for vehicles without ABS
  • Vendor BOSCH
  • SKU 0986487568
  • Barcode 4047026850505
  • CITROËN : 4241 K5 4241 N1
  • PEUGEOT : 4241 K5 4241 N1
  • TALBOT : 4241K5
  • APEC : BSH1012
  • APEC : SHU565
  • BORG & BECK : BBS6283
  • BREMBO : S 61 525
  • DELPHI : LS1848
  • DELPHI : LY1061
  • FEBI BILSTEIN : 33990
  • FTE : 9100057
  • HELLA : 8DB 355 001-881
  • HELLA : 8DB 355 004-511
  • MEYLE : 11-14 533 0005
  • MINTEX : MFR448
  • NAPA : NBS1030
  • National : NS4016
  • TEXTAR : 91053800
  • TRW : GS8642
  • VALEO : 562650
  • BOSCH : BS813
