BOSCH

Bosch 0986487600 Brake Shoe Set

SKU: 0986487600

Your selected vehicle

Only 5 left

Low inventory - Hurry! — Order by 17:00 for same-day dispatch

£25.78 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

SMART

CABRIO (450)

Description	Cylinder Capacity	Horse Power	Year
0.6 (S1OLA1, 450.441, 450.442, 450.443)	599 CCM	55 HP	03/2000 - 01/2004
0.8 CDI (S1OLC1, 450.401, 450.402, 450.403, 450.400)	799 CCM	41 HP	03/2001 - 01/2004
0.6 (S1OLD2, 450.452)	599 CCM	61 HP	01/2001 - 01/2004
0.7 (450.452, 450.432)	698 CCM	61 HP	01/2003 - 01/2004
0.7 (450.433)	698 CCM	75 HP	01/2003 - 01/2004
0.6 (450.432)	599 CCM	71 HP	06/2002 - 01/2004

CITY-COUPE (450)

Description	Cylinder Capacity	Horse Power	Year
0.6 (S1CLB1, 450.331, 450.336)	599 CCM	45 HP	07/1998 - 01/2004
0.6 (S1CLA1, 450.341)	599 CCM	55 HP	07/1998 - 01/2004
0.8 CDI (S1CLC1, 450.300, 450.301, 450.302, 450.303,...	799 CCM	41 HP	11/1999 - 01/2004
0.6 (450.352, 450.353)	599 CCM	61 HP	01/2001 - 01/2004
0.7 (450.330)	698 CCM	50 HP	01/2003 - 01/2004
0.7 (450.352, 450.332)	698 CCM	61 HP	01/2003 - 01/2004
0.7 (450.333)	698 CCM	75 HP	01/2003 - 01/2004
0.6 (450.330)	599 CCM	71 HP	06/2002 - 01/2004

CROSSBLADE (450)

Description	Cylinder Capacity	Horse Power	Year
0.6 (450.418)	599 CCM	71 HP	06/2002 - 12/2003

FORTWO Coupe (450)

Description	Cylinder Capacity	Horse Power	Year
0.7 (450.330)	698 CCM	50 HP	01/2004 - 01/2007
0.7 (450.352, 450.332)	698 CCM	61 HP	01/2004 - 01/2007
0.7 (450.333)	698 CCM	75 HP	01/2004 - 01/2007
0.8 CDI (450.300, 450.301, 450.302, 450.303, 450.306)	799 CCM	41 HP	01/2004 - 01/2007
0.7 (450.335)	698 CCM	54 HP	01/2004 - 01/2007

FORTWO Cabrio (450)

Description	Cylinder Capacity	Horse Power	Year
0.7 (450.452)	698 CCM	61 HP	01/2004 - 01/2007
0.7 (450.433)	698 CCM	75 HP	01/2004 - 01/2007
0.8 CDI (450.401, 450.402, 450.403, 450.400)	799 CCM	41 HP	01/2004 - 01/2007
0.6 Brabus (450.433)	599 CCM	75 HP	01/2004 - 12/2006

ROADSTER Coupe (452)

Description	Cylinder Capacity	Horse Power	Year
0.7 (452.334)	698 CCM	82 HP	04/2003 - 11/2005
0.7 Brabus (452.337)	698 CCM	101 HP	12/2003 - 11/2005
0.7 (452.332)	698 CCM	61 HP	06/2003 - 11/2005

ROADSTER (452)

Description	Cylinder Capacity	Horse Power	Year
0.7 (452.434)	698 CCM	82 HP	04/2003 - 11/2005
0.7 (452.432)	698 CCM	61 HP	04/2003 - 11/2005
0.7 Brabus (452.437)	698 CCM	101 HP	12/2003 - 11/2005

The Bosch 0986487600 Brake Shoe Set is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records 203 mm inner brake drum diameter, 32 mm width, with lining brake lining, and rear axle fitting position. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Shoe Set

Inner brake drum diameter [mm] : 203

Width [mm] : 32

Brake Lining : with lining

Engine Code : M 160.910

Fitting Position : Rear Axle

APEC : BSH1108
APEC : SHU625
BORG & BECK : BBS6309
BREMBO : S 50 504
DELPHI : LAJ1000
DELPHI : LY1365
FEBI BILSTEIN : 23106
FEBI BILSTEIN : 34476
FTE : 9100064
HELLA : 8DB 355 002-421
HELLA : 8DB 355 004-801
HELLA : 8DB 355 004-941
MEYLE : 014 533 0000
MEYLE : 014 533 0000/K
MINTEX : MFR484
NAPA : NBS1040
TEXTAR : 91057400
TRW : GS8685
VALEO : 564013

Bosch 0986487600 Brake Shoe Set
