Bosch 0986487616 Brake Shoe Set

SKU: 0986487616

Your selected vehicle

Only 2 left

Low inventory - Hurry! — Order by 17:00 for same-day dispatch

£24.32 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

SUZUKI

GRAND VITARA I (FT, HT)

Description	Cylinder Capacity	Horse Power	Year
2.5 V6 24V 4x4 (TD62, SQ625)	2493 CCM	144 HP	04/1998 - 07/2003
1.6 4x4 (SQ416)	1590 CCM	94 HP	01/2001 - 12/2005
2.0 4x4 (SQ420)	1995 CCM	128 HP	05/1999 - 09/2005
2.0 TD 4x4 (SQ420D)	1998 CCM	87 HP	03/1998 - 07/2003
2.0 HDI 110 16V 4x4 (SQ420D, TD83V, JA420WD)	1997 CCM	109 HP	07/2001 - 09/2005
2.5 V6 24V 4x4 (SQ625)	2493 CCM	158 HP	08/2004 - 11/2005
1.6 4x4 (SQ416)	1590 CCM	97 HP	09/2003 - 09/2005
2.0 4x4 (SQ 420)	1995 CCM	140 HP	04/1998 - 08/2005
2.0 TD 4x4 (SQ 420D)	1998 CCM	86 HP	04/2000 - 09/2005
2.0 HDI 110 4x4 (SQ420D, TD82V)	1997 CCM	109 HP	02/2001 - 12/2003
2.0 4x4 (SQ 420)	1995 CCM	132 HP	08/1998 - 11/2004
2.5 V6 24V 4x4	2493 CCM	160 HP	09/2003 - 09/2005

GRAND VITARA I Open Off-Road Vehicle (GT)

Description	Cylinder Capacity	Horse Power	Year
1.6 4x4 (SQ416)	1590 CCM	94 HP	03/1998 - 07/2003
2.0 4x4 (SQ420)	1995 CCM	128 HP	03/1998 - 07/2003

VITARA / ESCUDO (ET, TA, TD)

Description	Cylinder Capacity	Horse Power	Year
1.6 All-wheel Drive (SE416, TA01)	1589 CCM	82 HP	07/1988 - 12/1995

The Bosch 0986487616 Brake Shoe Set is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records 220 mm inner brake drum diameter, 42 mm width, with lining brake lining, and rear axle fitting position. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Shoe Set

Inner brake drum diameter [mm] : 220

Width [mm] : 42

Brake Lining : with lining

Fitting Position : Rear Axle

APEC : BSH1081
APEC : SHU582
BLUE PRINT : ADK84128
BORG & BECK : BBS6290
BREMBO : S 79 521
DELPHI : LS1882
DELPHI : LY1421
FTE : 9100058
HELLA : 8DB 355 001-921
MEYLE : 33-14 533 0003
MINTEX : MFR464
NAPA : NBS1034
TEXTAR : 91057600
TRW : GS8670
VALEO : 562784
