BOSCH

Bosch 0986487719 Handbrake Shoe Set

SKU: 0986487719

Your selected vehicle

Only 1 left

Low inventory - Hurry! — Order by 17:00 for same-day dispatch

£34.99 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

MITSUBISHI

PAJERO/SHOGUN Canvas Top (V2_C, V4_C)

Description	Cylinder Capacity	Horse Power	Year
2.5 TD 4WD (V24C)	2477 CCM	99 HP	12/1990 - 04/2000
3.0 V6 (V23C)	2972 CCM	150 HP	12/1990 - 12/1995
3.0 V6 24V (V23C)	2972 CCM	181 HP	06/1994 - 04/2000
2.4 (V21C)	2351 CCM	112 HP	04/1991 - 04/2000
2.5 TDiC (V24W, V24C)	2477 CCM	99 HP	03/1991 - 08/1999
3.0 V6 24V (V23C)	2972 CCM	177 HP	06/1994 - 04/2000

PAJERO/SHOGUN Mk II (V3_W, V2_W, V4_W, V5_W)

Description	Cylinder Capacity	Horse Power	Year
2.5 TD 4WD (V24W)	2477 CCM	99 HP	12/1990 - 10/1999
3.0 V6 4WD (V23W, V43W)	2972 CCM	150 HP	12/1990 - 12/1997
3.5 V6 24V (V25W, V45W)	3497 CCM	208 HP	06/1994 - 10/1999
2.8 TD (V46W, V26W)	2835 CCM	125 HP	06/1994 - 10/1999
3.0 V6 24V (V43W, V23W)	2972 CCM	181 HP	06/1994 - 05/1997
2.4 (V21W)	2351 CCM	112 HP	04/1991 - 10/1999
3.5 V6 24V (V45W, V25W)	3497 CCM	194 HP	07/1997 - 10/1999
3.0 V6 24V (V43W, V23W)	2972 CCM	177 HP	06/1997 - 10/1999
2.5 TDiC (V44W, V24W)	2477 CCM	99 HP	03/1991 - 08/1999
3.5 4WD (V25W, V45W)	3497 CCM	203 HP	09/1996 - 10/1999
2.8 D (V46W, V26W)	2835 CCM	140 HP	11/1993 - 10/1999
3.0 4WD	2972 CCM	177 HP	11/1997 - 04/2000

The Bosch 0986487719 Handbrake Shoe Set is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records 40 mm width, 196.6 mm inner brake drum diameter, and rear axle fitting position. It is listed in the brake Shoe Set, parking brake product category. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Shoe Set, parking brake

Width [mm] : 40

Inner brake drum diameter [mm] : 196.6

Engine Code : 4G64 Kat.

Construction Year to : 10.1993

Fitting Position : Rear Axle

Bosch 0986487719 Handbrake Shoe Set
