Bosch 0986487757 Brake Shoe Set

SKU: 0986487757

Your selected vehicle

In stock

Order by 17:00 for same-day dispatch

£21.05 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

KIA

PICANTO I (SA)

Description	Cylinder Capacity	Horse Power	Year
1.1	1086 CCM	65 HP	04/2004 - 09/2011
1.0	999 CCM	61 HP	04/2004 - 04/2011
1.1 CRDi	1120 CCM	75 HP	10/2005 - 04/2011
1.0	999 CCM	63 HP	09/2007 - 04/2011

The Bosch 0986487757 Brake Shoe Set is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records 180 mm inner brake drum diameter, 31.5 mm width, with lining brake lining, and rear axle fitting position. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Shoe Set

Inner brake drum diameter [mm] : 180

Width [mm] : 31.5

Brake Lining : with lining

Engine Code : G4HE

Construction Year from : 05.2004

Construction Year to : 01.2011

Fitting Position : Rear Axle

APEC : BSH1125
APEC : SHU717
BLUE PRINT : ADG04155
BORG & BECK : BBS6397
BREMBO : S 30 538
DELPHI : LAJ1013
DELPHI : LS2005
DELPHI : LY1356
FTE : 9100125
HELLA : 8DB 355 000-411
MINTEX : MFR666
NAPA : NBS1064
TEXTAR : 91072900
TRW : GS8754
