BOSCH

Bosch 0986487759 Brake Shoe Set

SKU: 0986487759
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£25.49 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

DAIHATSU
CHARADE VIII
Description Cylinder Capacity Horse Power Year
1.33 16V 1329 CCM 99 HP From 05/2011
TOYOTA
YARIS Hatchback Van (_P13_)
Description Cylinder Capacity Horse Power Year
1.0 VVTi (KSP130) 998 CCM 69 HP 07/2014 - 06/2020
1.4 D4d (NLP130) 1364 CCM 90 HP 07/2014 - 05/2018
1.0 VVTi (KSP130) 998 CCM 72 HP 06/2018 - 06/2020
YARIS/VITZ (_P9_)
Description Cylinder Capacity Horse Power Year
1.33 VVT-i (NSP90_, NSP90R) 1329 CCM 99 HP 07/2010 - 05/2011
1.0 VVT-i (KSP90_, KSP90R) 998 CCM 69 HP 08/2005 - 12/2011
1.4 D-4D (NLP90_, NLP90R) 1364 CCM 90 HP 08/2005 - 12/2012
1.3 VVT-i (SCP90_, SCP90R) 1298 CCM 87 HP 08/2005 - 11/2010
1.33 VVT-i (NSP90_, NSP90R) 1329 CCM 100 HP 11/2008 - 12/2011
1.0 VVT-i (KSP90) 998 CCM 71 HP 11/2005 - 11/2010
YARIS/VITZ (_P13_)
Description Cylinder Capacity Horse Power Year
1.3 (NSP130_, NSP130) 1329 CCM 95 HP 12/2010 - 07/2014
1.0 (KSP130_, KSP130) 998 CCM 69 HP 12/2010 - 06/2020
1.4 D (NLP130_, NLP130) 1364 CCM 90 HP 09/2011 - 05/2018
1.3 (NSP130_, NSP130) 1329 CCM 99 HP 09/2011 - 03/2017
1.5 (NSP131_) 1496 CCM 112 HP 03/2017 - 06/2020
1.0 (KSP130) 998 CCM 72 HP 06/2018 - 06/2020

The Bosch 0986487759 Brake Shoe Set is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records 203.2 mm inner brake drum diameter, 38 mm width, with lining brake lining, and rear axle fitting position. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Shoe Set
Inner brake drum diameter [mm] : 203.2
Width [mm] : 38
Brake Lining : with lining
Construction Year to : 12.2013
Fitting Position : Rear Axle
  • Vendor BOSCH
  • SKU 0986487759
  • Barcode 4047026851120
  • DAIHATSU : 044950D040
  • TOYOTA : 044950D040 044950D090
  • APEC : BSH1065
  • APEC : SHU753
  • BLUE PRINT : ADT34179
  • BORG & BECK : BBS6414
  • BREMBO : S 83 513
  • DELPHI : LS2021
  • DELPHI : LY1335
  • DELPHI : LY1431
  • FTE : 9100172
  • HELLA : 8DB 355 000-471
  • HELLA : 8DB 355 022-791
  • MEYLE : 30-14 533 0025
  • MEYLE : 30-14 533 0025/K
  • MINTEX : MFR639
  • NAPA : NBS1069
  • National : NS4095
  • TEXTAR : 91075000
  • TRW : GS8778
  • VALEO : 564108
  • BOSCH : BS979
