BOSCH

Bosch 0986487922 Brake Shoe Set

SKU: 0986487922
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£33.38 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

FORD
RANGER (TKE)
Description Cylinder Capacity Horse Power Year
2.2 TDCi 2198 CCM 125 HP From 04/2011
2.2 TDCi 4x4 2198 CCM 125 HP From 04/2011
2.2 TDCi 4x4 2198 CCM 150 HP From 04/2011
3.2 TDCi 4x4 3198 CCM 200 HP From 04/2011
2.5 i 4x4 2488 CCM 166 HP From 11/2011
2.2 TDCi 2198 CCM 150 HP From 11/2011
2.2 TDCi 2198 CCM 160 HP From 05/2015
2.2 TDCi 4x4 2198 CCM 160 HP From 05/2015
2.2 TDCi 2198 CCM 131 HP From 05/2015
2.2 TDCi 4x4 2198 CCM 131 HP From 05/2015
2.0 EcoBlue 4x4 1996 CCM 213 HP From 09/2018
2.0 EcoBlue 4x4 1996 CCM 131 HP From 03/2019
2.0 EcoBlue 4x4 1996 CCM 170 HP From 03/2019
NISSAN
NAVARA NP300 (D40)
Description Cylinder Capacity Horse Power Year
2.5 dCi 4WD (D40TT, D40T, D40M, D40BB) 2488 CCM 190 HP From 12/2009
3.0 dCi 4WD 2993 CCM 231 HP From 02/2010
2.5 dCi 2488 CCM 144 HP From 07/2005
2.5 dCi 4WD 2488 CCM 174 HP From 07/2005
2.5 dCi 4WD 2488 CCM 171 HP From 10/2006
2.5 dCi 2488 CCM 163 HP From 10/2006
2.5 dCi 4WD 2488 CCM 144 HP From 01/2007
NAVARA NP300 Platform/Chassis (D40)
Description Cylinder Capacity Horse Power Year
2.5 dCi 2488 CCM 190 HP From 03/2010
3.0 dCi 2993 CCM 231 HP From 03/2010
2.5 dCi 4WD 2488 CCM 171 HP From 08/2008
2.5 dCi 4WD 2488 CCM 144 HP From 08/2008
NAVARA NP300 Pickup (D23, D23T)
Description Cylinder Capacity Horse Power Year
2.3 dCi 4x4 (D231) 2298 CCM 163 HP From 01/2015
2.3 dCi 4x4 (D231, D23T) 2298 CCM 190 HP From 10/2015
NAVARA NP300 Platform/Chassis (D23)
Description Cylinder Capacity Horse Power Year
2.3 dCi 4x4 2298 CCM 163 HP From 01/2015
RENAULT
ALASKAN
Description Cylinder Capacity Horse Power Year
2.3 dCi 163 4x4 (U3MB) 2298 CCM 163 HP From 09/2017

The Bosch 0986487922 Brake Shoe Set is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records 1 987 475 419 and 1 987 475 344 article number of recommended accessories, 294 mm inner brake drum diameter, 56.3 mm width, and rear axle fitting position. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Shoe Set
Article number of recommended accessories : 1 987 475 419
Article number of recommended accessories : 1 987 475 344
Inner brake drum diameter [mm] : 294
Width [mm] : 56.3
Brake Lining : with lining
Engine Code : YL2X
Fitting Position : Rear Axle
  • Vendor BOSCH
  • SKU 0986487922
  • Barcode 4047026843668
  • FORD : AB312200BA 1727211
  • MITSUBISHI : D4060EB36A
  • NISSAN : D4060EB36A 44060 EB326 44060 EB327
  • APEC : BSH1136
  • APEC : SHU795
  • BLUE PRINT : ADN14166
  • BORG & BECK : BBS6445
  • BREMBO : S 56 547
  • DELPHI : LAJ1023
  • DELPHI : LS2080
  • DELPHI : LY1308
  • DELPHI : LY1420
  • FTE : 9100176
  • HELLA : 8DB 355 022-241
  • MEYLE : 36-14 533 0008
  • MINTEX : MFR735
  • NAPA : NBS1077
  • National : NS4102
  • TEXTAR : 91081800
  • TRW : GS8797
  • BOSCH : BS7922
