BOSCH

Bosch 0986494935 Brake Pad Set, disc brake

SKU: 0986494935
Your selected vehicle
Only 2 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£25.25 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

FIAT
PANDA (312_, 319_)
Description Cylinder Capacity Horse Power Year
1.3 D Multijet 4x4 (312PXL1A) 1248 CCM 75 HP From 06/2012
0.9 4x4 (312PXG1A) 875 CCM 86 HP From 09/2012
0.9 4x4 (312PXR2B) 875 CCM 90 HP From 06/2014
1.3 D Multijet 4x4 (312PXS2A) 1248 CCM 80 HP From 06/2014
PANDA VAN (312_, 519_)
Description Cylinder Capacity Horse Power Year
0.9 4x4 (312CXG2B) 875 CCM 86 HP From 09/2012
1.3 D Multijet 4x4 (312CXL2A) 1248 CCM 75 HP From 06/2012
1.3 D Multijet 4x4 (312PXS2A) 1248 CCM 80 HP From 06/2014

The Bosch 0986494935 Brake Pad Set, disc brake is a friction component for the vehicle braking system that provides the replaceable friction material used to slow the relevant disc or drum. Its catalogue specification records with integrated wear warning contact and with acoustic wear warning, with spring and with accessories, low-Metallic construction, and test mark ECE-R90. Match the reference, dimensions, brake system, axle application and wear-sensor provision before fitting; braking components should be installed and checked by a competent person.

Function : Brake Pad Set, disc brake
Wear Warning Contact : with integrated wear warning contact
Wear Warning Contact : with acoustic wear warning
Supplementary Article/Supplementary Info : with spring
Supplementary Article/Supplementary Info : with accessories
Supplementary Article/Supplementary Info 2 : with bolts/screws
Article number of recommended accessories : 1 987 474 316
Material : Low-Metallic
Test Mark : ECE-R90
WVA Number : 25410
Thickness [mm] : 14.4
Width [mm] : 95.5
Height [mm] : 43.5
Number of bolts/screws : 4
Number of springs : 4
  • Vendor BOSCH
  • SKU 0986494935
  • Barcode 4047026124187
  • FIAT : K68088919AB 68088919AA 68088919AB 77366388 77366453 77367514
  • APEC : PAD1873
  • APEC : PD3289
  • BLUE PRINT : ADBP420054
  • BLUE PRINT : ADL144205
  • BORG & BECK : BBP2440
  • BORG & BECK : BBP2620
  • BREMBO : P 23 151
  • DELPHI : LP2761
  • DELPHI : LX0342
  • FEBI BILSTEIN : 16370
  • FEBI BILSTEIN : 175268
  • FTE : 9010974
  • HELLA : 8DB 355 023-271
  • MEYLE : 025 254 1014
  • MINTEX : MDB3813
  • National : NP2940
  • SKF : VKBP 90808 A
  • TEXTAR : 2541101
  • TRW : GDB1950
  • BOSCH : BP1924
  • BOSCH : E9-90R-02A1180/4783
  • BOSCH : 25651
