BOSCH

Bosch 1986A01022 Alternator

SKU: 1986A01022
Only 1 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£288.48 inc. VAT
Pay in 3 interest-free payments with Klarna

Free UK delivery

Free shipping available on all orders across the UK.

  • Royal Mail Tracked 48 = Free
  • Royal Mail Tracked 24 = £2.99
  • FedEx Next Day = £4.99
Function : Alternator
Voltage [V] : 24
Alternator Charging Current [A] : 120
Fastening Type : Double Pivot Lever
Alternator Type : excl. vacuum pump
Distance from belt pulley to alternator [mm] : 44.5
Rotation Direction : Clockwise rotation
Pulleys : with multi-belt pulley
Number of grooves : 8
Belt Pulley Ø [mm] : 72
Clamp : B+(M8)
Plug Type ID : 82
Length [mm] : 223
Recommended additional repairs : V-Belt/V-ribbed Belt
  • Vendor BOSCH
  • SKU 1986A01022
  • Barcode 4047026550467
  • MAGIRUS-DEUTZ : 01183602 11583602 118 3602
  • VOLVO : 15196041 20741686 21429790 21679866 22218391
  • BOSCH : 0 986 085 310
  • Carwood Group : BREF0320986085310
  • Carwood Group : BREF032114078
  • Carwood Group : BREF0321986A01022
  • HELLA : 8EL 012 584-781
  • MAHLE : MG 817
  • VALEO : 202039
  • VALEO : 443497
  • WAI : 20243N
  • BOSCH : ALT 28V 120A (R)
