Bosch 1986A01514 Alternator
Your selected vehicle
Regular price
£243.91
inc. VAT
Pay in 3 interest-free payments with Klarna
Standard delivery
Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.
The Bosch 1986A01514 Alternator is a replacement starting or charging-system component that supports electrical power generation, storage or engine cranking in the vehicle. Its catalogue specification records 14 V electrical rating, Double Pivot Lever fastening type, excl. vacuum pump alternator type, and 61 plug type id. Match the reference, voltage, output or capacity, terminals, mounting and vehicle application before fitting; isolate the electrical system and follow the manufacturer's coding procedure where required.
Function :
Alternator
Voltage [V] :
14
Alternator Charging Current [A] :
110
Fastening Type :
Double Pivot Lever
Alternator Type :
excl. vacuum pump
Distance from belt pulley to alternator [mm] :
39.6
Rotation Direction :
Clockwise rotation
Pulleys :
with multi-belt pulley
Number of grooves :
6
Belt Pulley Ø [mm] :
50
Clamp :
B+(M8)
Plug Type ID :
61
Length [mm] :
187
Recommended additional repairs :
V-Belt/V-ribbed Belt
Vehicle Equipment :
for vehicles without air conditioning
Engine Code :
CGGB
Construction Year from :
05.2010
Manufacturer Restriction :
Bosch
Engine Code :
BXW
Construction Year to :
05.2010
Construction Year to :
05.2013
- Vendor BOSCH
- SKU 1986A01514
- AUDI : 036 903 024 E
- SEAT : 036 903 024 M
- SKODA : 036 903 024 M
- VW : 036 903 024 E 036 903 024 EX 036 903 024 M 036 903 024 MX
- BOSCH : 0 986 045 310
- Carwood Group : BREF032116587
- Carwood Group : BREF0321986A01514
- VALEO : 443004
- BOSCH : ALT 14V 110A (R)
