Bosch 1986S01044 Starter Motor
Your selected vehicle
Regular price
£200.75
inc. VAT
Pay in 3 interest-free payments with Klarna
Standard delivery
Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.
The Bosch 1986S01044 Starter Motor is a replacement starting or charging-system component that supports electrical power generation, storage or engine cranking in the vehicle. Its catalogue specification records 12 V electrical rating, 1.5 kW rated power, 12 teeth, and Self-supporting starter type. Match the reference, voltage, output or capacity, terminals, mounting and vehicle application before fitting; isolate the electrical system and follow the manufacturer's coding procedure where required.
Function :
Starter
Voltage [V] :
12
Rated Power [kW] :
1.5
Number of mounting bores :
0
Number of threaded holes :
3
Number of Teeth :
12
Clamp :
50
Clamp :
30
Flange Diameter [mm] :
64
Rotation Direction :
Clockwise rotation
Pinion Rest Position [mm] :
1
Starter Type :
Self-supporting
Thread Size :
M10x1,5
Thread Size 1 :
M10x1,5
Thread Size 2 :
M10x1,5
Length [mm] :
195
Position/Degree :
links
Mounting Angle [degrees] :
47
Jaw opening angle measurement [Degree] :
72
Mounting bore angle measurement [degree] :
47
Construction Year to :
12.2018
for OE number :
23 30 006 86R
Manufacturer Restriction :
VALEO
Construction Year to :
12.2019
- Vendor BOSCH
- SKU 1986S01044
- RENAULT : 23 30 006 86R
- BOSCH : 0 986 026 840
- Carwood Group : BREF0320986026840
- Carwood Group : BREF0321986S01044
- VALEO : 438534
- BOSCH : ST 12V 1,5KW (R)
