DELPHI

Delphi HDF657 Fuel Filter

SKU: HDF657
Your selected vehicle
Only 4 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£11.43 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

TOYOTA
HIACE V Van (TRH2__, KDH2__, LH2__, GDH2__)
Description Cylinder Capacity Horse Power Year
3.0 D (KDH221, KDH201) 2982 CCM 136 HP From 05/2010
2.5 D-4D (KDH20_, KDH21_, KDH22_, KDH200, KDH220) 2494 CCM 102 HP From 06/2004
3.0 D (KDH201, KDH203, KDH221) 2982 CCM 144 HP From 11/2008
2.5 D-4D 2494 CCM 95 HP From 09/2006
2.5 D-4D (KDH200, KDH202, KDH212, KDH222) 2494 CCM 117 HP From 09/2006
HIACE / COMMUTER V Bus (TRH2__, KDH2__, LH2__, GDH2__)
Description Cylinder Capacity Horse Power Year
3.0 D (KDH223) 2982 CCM 136 HP From 05/2010
2.5 D-4D (KDH202) 2494 CCM 102 HP From 09/2006
HILUX VIGO VII Pickup (_N1_, _N2_, _N3_)
Description Cylinder Capacity Horse Power Year
2.5 D-4D (KUN15, KUN35) 2494 CCM 144 HP 01/2010 - 05/2015
2.5 D 4WD (KUN25) 2494 CCM 102 HP 03/2005 - 05/2015
2.5 D-4D 4WD (KUN25_, KUN25R) 2494 CCM 120 HP 06/2006 - 05/2015
2.5 D-4D (KUN15_, KUN15R) 2494 CCM 120 HP 06/2006 - 05/2015
3.0 D-4D 4WD (KUN26) 2982 CCM 171 HP 08/2005 - 09/2015
2.5 D-4D (KUN15, KUN10) 2494 CCM 102 HP 03/2005 - 05/2015
3.0 D-4D 4WD (KUN26) 2982 CCM 163 HP 03/2005 - 05/2015
2.5 D-4D 4WD (KUN25) 2494 CCM 144 HP 12/2007 - 05/2015
2.5 D-4D 4WD (KUN25_) 2494 CCM 128 HP 11/2004 - 12/2005
3.0 D-4D 4WD (KUN26) 2982 CCM 197 HP 05/2008 - 12/2012
2.5 D-4D (KUN15) 2494 CCM 88 HP 08/2005 - 10/2006
HILUX VII Platform/Chassis (_N1_, _N2_)
Description Cylinder Capacity Horse Power Year
3.0 D 4WD (KUN26) 2982 CCM 171 HP From 02/2005
LEXUS
IS II (_E2_)
Description Cylinder Capacity Horse Power Year
200d (ALE20_, ALE20R) 2231 CCM 150 HP 07/2010 - 07/2012
220d (ALE20) 2231 CCM 177 HP 08/2005 - 07/2012

The Delphi HDF657 Fuel Filter is a replacement filtration component that helps retain contamination while allowing the relevant air, oil, fuel or cabin-air flow. Its catalogue specification records 84 mm diameter, metal construction, filter Insert filter design, and 77 mm height. Compare the reference, filter design, dimensions and vehicle application data below with the removed part before ordering, because filter formats can vary within the same model range.

Function : Fuel Filter
Diameter [mm] : 84
Material : Metal
Filter type : Filter Insert
Height [mm] : 77
  • Vendor DELPHI
  • SKU HDF657
  • Barcode 5050100304046
  • TOYOTA : 23390-0L030 2339030200 23390-0L041 233900L040 23390-0L011 23390-0L010 23300-87317 18604-00021 23390-0L020
  • LEXUS : 233900L030 2339030200 233900L041 233900L010 233900L040
  • BLUE PRINT : ADT32381
  • BORG & BECK : BFF8096
  • BORG & BECK : BFF8258
  • BOSCH : F 026 402 364
  • Fahren : FFF5066
  • FEBI BILSTEIN : 184132
  • HELLA : 8ZF 366 111-991
  • HENGST FILTER : E492KP D371
  • LUCAS : LFDE197
  • MAHLE : KX 268D
  • NAPA : NFF2141
  • UFI : 26.045.00
  • WIX FILTERS : WF8429
  • User manual
