DELPHI

Delphi TA1496 Tie Rod End

SKU: TA1496
Your selected vehicle
Only 2 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£16.48 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

VOLVO
850 (854)
Description Cylinder Capacity Horse Power Year
2.0 1984 CCM 143 HP 06/1991 - 12/1996
2.4 2435 CCM 140 HP 06/1991 - 07/1994
2.4 2435 CCM 170 HP 08/1991 - 12/1996
2.4 2435 CCM 144 HP 08/1994 - 12/1996
2.0 1984 CCM 126 HP 08/1994 - 12/1996
2.5 TDI 2460 CCM 140 HP 08/1995 - 12/1996
2.0 Turbo 1984 CCM 210 HP 08/1993 - 12/1996
T5 2319 CCM 226 HP 08/1993 - 07/1996
T5-R 2319 CCM 250 HP 08/1995 - 12/1996
2.0 Turbo 1984 CCM 179 HP 09/1993 - 10/1996
T5 R 2319 CCM 239 HP 04/1996 - 10/1996
2.3 Turbo R 2319 CCM 241 HP 06/1995 - 10/1996
2.3 2319 CCM 144 HP 01/1996 - 10/1996
2.4 GLE 2435 CCM 193 HP 09/1993 - 10/1997
2.3 Turbo R 2319 CCM 243 HP 09/1994 - 10/1997
850 Estate (855)
Description Cylinder Capacity Horse Power Year
2.4 2435 CCM 170 HP 09/1992 - 12/1996
2.0 1984 CCM 126 HP 08/1994 - 12/1996
2.4 2435 CCM 140 HP 08/1992 - 07/1994
2.5 TDI 2460 CCM 140 HP 08/1995 - 12/1996
2.0 1984 CCM 143 HP 02/1993 - 12/1996
2.0 Turbo 1984 CCM 210 HP 02/1993 - 12/1996
2.4 2435 CCM 144 HP 08/1994 - 12/1996
2.4 AWD 2435 CCM 193 HP 04/1996 - 10/1997
T5 2319 CCM 226 HP 02/1993 - 12/1996
T5-R 2319 CCM 250 HP 08/1995 - 12/1996
T5 R 2319 CCM 239 HP 04/1996 - 10/1996
2.3 Turbo R 2319 CCM 241 HP 06/1995 - 10/1997
2.3 Turbo R 2319 CCM 243 HP 09/1994 - 10/1997
960 Mk II (964)
Description Cylinder Capacity Horse Power Year
2.9 2922 CCM 204 HP 07/1994 - 12/1996
2.5 2473 CCM 170 HP 07/1994 - 12/1996
960 Mk II Estate (965)
Description Cylinder Capacity Horse Power Year
2.9 2922 CCM 204 HP 09/1994 - 12/1996
2.5 2473 CCM 170 HP 08/1994 - 12/1996
C70 I Coupe (872)
Description Cylinder Capacity Horse Power Year
2.0 T 1984 CCM 226 HP 03/1997 - 09/2002
2.0 1984 CCM 180 HP 03/1997 - 09/2002
T-5 2319 CCM 240 HP 03/1997 - 09/2002
2.4 T 2435 CCM 193 HP 03/1997 - 09/2002
2.4 2435 CCM 165 HP 03/1999 - 09/2002
2.4 2435 CCM 170 HP 05/1999 - 09/2002
2.0 T 1984 CCM 163 HP 03/2000 - 09/2002
C70 I Convertible (873)
Description Cylinder Capacity Horse Power Year
2.0 1984 CCM 180 HP 03/1998 - 10/2005
2.0 T 1984 CCM 226 HP 03/1998 - 10/2005
T5 2319 CCM 239 HP 03/1998 - 10/2005
2.4 T 2435 CCM 193 HP 03/1998 - 10/2005
2.4 2435 CCM 170 HP 06/1998 - 10/2005
2.0 T 1984 CCM 163 HP 03/2000 - 10/2005
2.4 T 2435 CCM 200 HP 04/1999 - 08/2002
T5 2319 CCM 245 HP 07/2002 - 10/2005
S70 (874)
Description Cylinder Capacity Horse Power Year
2.0 1984 CCM 126 HP 01/1997 - 11/2000
2.4 2435 CCM 144 HP 01/1997 - 11/2000
2.4 2435 CCM 170 HP 01/1997 - 11/2000
2.4 Turbo 2435 CCM 193 HP 01/1997 - 11/2000
T5 2319 CCM 239 HP 01/1997 - 11/2000
2.5 TDI 2460 CCM 140 HP 01/1997 - 11/2000
2.0 1984 CCM 143 HP 01/1997 - 11/2000
2.0 Turbo 1984 CCM 210 HP 01/1997 - 11/2000
2.3 Turbo 2319 CCM 250 HP 01/1997 - 11/2000
2.0 Turbo 1984 CCM 226 HP 01/1997 - 11/2000
2.0 1984 CCM 180 HP 01/1997 - 11/2000
2.4 Bifuel 2435 CCM 144 HP 10/1998 - 11/2000
2.4 2435 CCM 165 HP 06/1998 - 11/2000
2.4 2435 CCM 140 HP 08/1999 - 11/2000
2.4 Bifuel 2435 CCM 140 HP 07/1999 - 11/2000
S90 I (964)
Description Cylinder Capacity Horse Power Year
2.9 2922 CCM 180 HP 01/1997 - 05/1998
2.9 2922 CCM 204 HP 01/1997 - 05/1998
V70   (875, 876)
Description Cylinder Capacity Horse Power Year
2.0 1984 CCM 126 HP 12/1995 - 03/2000
2.4 2435 CCM 144 HP 12/1995 - 03/2000
2.4 2435 CCM 170 HP 12/1995 - 05/2000
2.4 Turbo 2435 CCM 193 HP 04/1996 - 12/2000
2.4 Turbo AWD 2435 CCM 193 HP 04/1996 - 12/2000
2.3 T-5 2319 CCM 239 HP 11/1996 - 12/2000
2.5 TDI 2460 CCM 140 HP 12/1995 - 12/2000
2.0 Turbo 1984 CCM 211 HP 12/1995 - 03/2000
2.0 1984 CCM 143 HP 12/1995 - 03/2000
2.3 Turbo 2319 CCM 250 HP 12/1995 - 03/2000
2.0 Turbo 1984 CCM 226 HP 11/1996 - 12/2000
2.0 1984 CCM 180 HP 11/1996 - 03/2000
2.0 Turbo AWD 1984 CCM 226 HP 11/1996 - 12/2000
2.3 T-5 AWD 2319 CCM 239 HP 01/1997 - 12/2000
2.4 Bifuel 2435 CCM 144 HP 05/1998 - 12/1999
V90 I Estate (965)
Description Cylinder Capacity Horse Power Year
2.9 2922 CCM 180 HP 01/1997 - 12/1998
2.9 2922 CCM 204 HP 01/1997 - 12/1998
XC70 I Cross Country (295)
Description Cylinder Capacity Horse Power Year
2.4 T XC AWD 2435 CCM 193 HP 11/1997 - 09/2002
T5 AWD 1984 CCM 226 HP 10/1997 - 03/1999

The Delphi TA1496 Tie Rod End is a replacement steering or suspension joint component that locates connected chassis parts while allowing their intended movement. Its catalogue specification records M14x2 thread size, with right-hand thread thread type, front axle right fitting position, and 196 mm length. Match the reference, side, axle position, joint or thread dimensions and vehicle application before fitting; steering geometry should be checked after replacement where applicable.

Function : Tie Rod End
Thread Size : M14x2
Thread Type : with right-hand thread
Cone Size [mm] : 12.9
Paired article number : TA1495
Fitting Position : Front Axle Right
Length [mm] : 196
Width [mm] : 53
Height [mm] : 76
  • Vendor DELPHI
  • SKU TA1496
  • Barcode 5012759851388
  • VOLVO : 271599 2715993 2715996 3546268
  • APEC : AST6135
  • BORG & BECK : BTR4777
  • BOSCH : 0 986 140 438
  • CORTECO : 49400899
  • FEBI BILSTEIN : 05760
  • FEBI BILSTEIN : 12748
  • FEBI BILSTEIN : 40568
  • FEBI BILSTEIN : 40570
  • FIRST LINE : FTR4777
  • LEMFÖRDER : 20137 02
  • MEYLE : 516 020 5548
  • MONROE : L27103
  • NAPA : NST6135
  • Schaeffler FAG : 840 0962 10
  • SKF : VKDY 316030
  • TRW : JTE339
