DELPHI

Delphi TA1545 Tie Rod End

SKU: TA1545
Your selected vehicle
Only 2 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£13.20 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

TOYOTA
4 RUNNER II (_N13_)
Description Cylinder Capacity Horse Power Year
3.0 TD (KZN130_, KZN130G, KZN130W) 2982 CCM 125 HP 10/1993 - 03/1996
3.0 EFI (VZN130_, VZN130G, VZN130R) 2959 CCM 143 HP 01/1990 - 10/1995
DYNA 100 Platform/Chassis (YH_)
Description Cylinder Capacity Horse Power Year
1.8 (YH81_, YH81R) 1812 CCM 83 HP 08/1987 - 04/1995
DYNA Platform/Chassis (LH8_)
Description Cylinder Capacity Horse Power Year
2.4 D (LH80_, LY50_, LY60_) 2446 CCM 83 HP 08/1985 - 05/1995
DYNA 100 Platform/Chassis (LY1_, YY1_)
Description Cylinder Capacity Horse Power Year
2.4 D (LY100_, LY100R) 2446 CCM 73 HP 05/1995 - 07/2001
HIACE III Bus (_H5_, _H6_, _H7_, _H8_, _H9_)
Description Cylinder Capacity Horse Power Year
2.0 (YH51, YH61) 1998 CCM 88 HP 01/1985 - 08/1989
2.4 D (LH51, LH61, LH66) 2446 CCM 75 HP 04/1984 - 08/1989
2.2 D (LH50, LH60) 2188 CCM 67 HP 12/1982 - 11/1989
1.8 (YH50, YH60) 1812 CCM 79 HP 03/1983 - 07/1989
2.4 D 4WD (LH56, LH66) 2446 CCM 73 HP 01/1987 - 08/1989
HIACE III Van (_H5_, _H6_, _H7_, _H8_, _H9_)
Description Cylinder Capacity Horse Power Year
1.8 (YH50, YH60) 1812 CCM 79 HP 12/1982 - 07/1989
2.2 D (LH50, LH60) 2188 CCM 67 HP 12/1982 - 11/1989
2.4 D (LH61, LH51) 2446 CCM 75 HP 12/1982 - 11/1989
2.0 (YH51, YH61) 1998 CCM 88 HP 12/1982 - 08/1989
HILUX II SUV (_N13_)
Description Cylinder Capacity Horse Power Year
2.4 TD 4WD (LN130_) 2446 CCM 125 HP 08/1988 - 08/1997
HILUX V Pickup (_N8_, _N9_, _N10_, _N11_)
Description Cylinder Capacity Horse Power Year
2.4 D (LN85, LN90) 2446 CCM 80 HP 10/1991 - 07/1997
2.4 EFI 4WD (RN106_, RN110_, RN106R, RN110R) 2367 CCM 114 HP 01/1989 - 07/1997
2.4 D 4WD (LN110_, LN110R) 2446 CCM 79 HP 01/1994 - 12/1997
1.8 (YN85, YN90) 1812 CCM 83 HP 09/1988 - 06/1998
2.4 D (LN90_, LN90R) 2446 CCM 79 HP 03/1995 - 08/1997
2.4 D (LN85_, LN110, LN90) 2446 CCM 83 HP 09/1988 - 08/1997
2.4 D (LN5_, LN85, LN90) 2446 CCM 75 HP 10/1988 - 07/1997
2.2 (YN87_, YN87R) 2237 CCM 94 HP 03/1989 - 07/1994
HILUX VI Pickup (_N1_)
Description Cylinder Capacity Horse Power Year
2.4 TD 4WD (LN165_, LN170_, LN190_, LN165, LN165H,... 2446 CCM 90 HP 08/1998 - 01/2002
2.4 D (LN150, LN145) 2446 CCM 75 HP 08/1997 - 04/2005
2.5 D-4D (KDN145, KDN150) 2494 CCM 88 HP 11/2001 - 07/2005
2.5 D-4D 4WD (KDN165, KDN170, KDN190) 2494 CCM 102 HP 11/2001 - 07/2005
2.4 D (LN145, LN150) 2446 CCM 79 HP 08/1997 - 07/2005
2.4 D (LN145, LN150) 2446 CCM 83 HP 08/1997 - 08/2001
VW
TARO
Description Cylinder Capacity Horse Power Year
1.8 1812 CCM 83 HP 04/1989 - 09/1994
2.4 D 2446 CCM 80 HP 09/1991 - 07/1994
2.2 2237 CCM 94 HP 06/1989 - 07/1994
2.4 i 4x4 2366 CCM 114 HP 06/1989 - 03/1997
2.4 D 4x4 2446 CCM 79 HP 07/1994 - 03/1997
2.4 D 2446 CCM 79 HP 07/1994 - 03/1997
2.4 D 2446 CCM 83 HP 06/1989 - 03/1997
2.4 D 4x4 2446 CCM 83 HP 04/1989 - 03/1997

The Delphi TA1545 Tie Rod End is a replacement steering or suspension joint component that locates connected chassis parts while allowing their intended movement. Its catalogue specification records M17x1.5 thread size, with right-hand thread thread type, front axle fitting position, and 112 mm length. Match the reference, side, axle position, joint or thread dimensions and vehicle application before fitting; steering geometry should be checked after replacement where applicable.

Function : Tie Rod End
Thread Size : M17x1.5
Thread Type : with right-hand thread
Cone Size [mm] : 14.6
Fitting Position : Front Axle
Length [mm] : 112
Width [mm] : 40
Height [mm] : 77
  • Vendor DELPHI
  • SKU TA1545
  • Barcode 5012759931349
  • AUDI : 4504639235
  • TOYOTA : 45046-39175 4504639375 45046-39385 4504639355 45046-39235 45046-39215 45046-39135 45046-39125 45046-39106 45046-39105 45046-29115 45046-29125 45046-39165
  • VW : J45 046 391 75 J45 046 392 35
  • APEC : AST6366
  • BLUE PRINT : ADT38702
  • BORG & BECK : BTR4378
  • CORTECO : 49400931
  • FEBI BILSTEIN : 23781
  • FEBI BILSTEIN : 43141
  • FIRST LINE : FTR4378
  • LEMFÖRDER : 11907 02
  • MEYLE : 30-16 020 0004
  • MONROE : L13014
  • NAPA : NST6366
  • Schaeffler FAG : 840 0608 10
  • SKF : VKDY 811048
  • TRW : JTE469
