DELPHI

Delphi TA1589 Tie Rod End

SKU: TA1589
Your selected vehicle
In stock
Orders placed by 17:00 are usually dispatched the same working day
£16.98 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

HONDA
ACCORD Mk IV Coupe (CB, CC)
Description Cylinder Capacity Horse Power Year
2.0 i 16V (CC1) 1997 CCM 133 HP 01/1992 - 09/1993
ACCORD Mk IV Aerodeck (CB)
Description Cylinder Capacity Horse Power Year
2.2 i 16V (CB8) 2156 CCM 147 HP 01/1991 - 12/1993
2.2 i 16V (CB8) 2156 CCM 150 HP 01/1991 - 12/1993
2.0 i 16V (CC9) 1997 CCM 133 HP 03/1993 - 12/1993
ACCORD Mk IV (CB)
Description Cylinder Capacity Horse Power Year
2.0 16V (CB3) 1997 CCM 90 HP 01/1990 - 03/1993
2.0 16V (CB3) 1997 CCM 110 HP 01/1990 - 03/1993
2.0 i 16V (CB3) 1997 CCM 133 HP 01/1990 - 03/1993
2.2 i 16V Automatik (CB7) 2156 CCM 147 HP 01/1990 - 03/1993
2.2 i 16V (CB7) 2156 CCM 150 HP 01/1990 - 03/1993
1.8 1829 CCM 105 HP 01/1990 - 12/1991
2.0 i 1997 CCM 135 HP 09/1990 - 04/1993
ACCORD Mk V (CC, CD)
Description Cylinder Capacity Horse Power Year
2.0 i (CD4) 1997 CCM 116 HP 03/1993 - 01/1996
2.0 i S (CD4) 1997 CCM 131 HP 03/1993 - 01/1996
2.3 i SR (CD6) 2259 CCM 158 HP 03/1993 - 01/1996
ACCORD Mk V Aerodeck (CE)
Description Cylinder Capacity Horse Power Year
2.0 i LS 16V (CE2) 1997 CCM 136 HP 09/1993 - 02/1998
2.2 i ES (CE1) 2156 CCM 150 HP 09/1993 - 02/1998
ACCORD Mk V Coupe (CD)
Description Cylinder Capacity Horse Power Year
2.2 i ES (CD7) 2156 CCM 150 HP 09/1993 - 02/1998
2.0 (CD9) 1997 CCM 136 HP 09/1993 - 12/1997
ACCORD Mk V (CE, CF_, CD)
Description Cylinder Capacity Horse Power Year
1.8 i (CE7) 1850 CCM 116 HP 02/1996 - 10/1998
2.0 i LS (CE8) 1997 CCM 131 HP 02/1996 - 10/1998
2.2 i VTEC (CE9) 2156 CCM 150 HP 02/1996 - 10/1998
2.0 TDi (CF1) 1994 CCM 105 HP 04/1996 - 10/1998
2.2 (CD5) 2156 CCM 140 HP 04/1996 - 12/1997
ACCORD VI (CK, CG, CH, CF, CL)
Description Cylinder Capacity Horse Power Year
1.8 i (CG8) 1850 CCM 136 HP 10/1998 - 12/2002
2.0 i (CG9) 1997 CCM 147 HP 10/1998 - 01/2001
2.2 Type-R (CH1) 2156 CCM 212 HP 02/1999 - 12/2002
2.0 Turbo DI (CH2) 1994 CCM 105 HP 02/1999 - 12/2002
1.6 i (CG7) 1590 CCM 116 HP 10/1998 - 12/2002
2.3 (CL3, S86) 2254 CCM 154 HP 01/2001 - 06/2003
ACCORD Mk VII Coupe (CG)
Description Cylinder Capacity Horse Power Year
2.0 i 16V 1997 CCM 147 HP 02/1998 - 06/2003
3.0 V6 24V (CG2) 2997 CCM 200 HP 02/1998 - 06/2003
2.0 1997 CCM 145 HP 11/1999 - 10/2002
ACCORD Mk VII Hatchback (CH, CL)
Description Cylinder Capacity Horse Power Year
1.8 i (CH6) 1850 CCM 136 HP 12/1999 - 12/2002
2.3 (CL4) 2254 CCM 154 HP 11/2000 - 12/2002
2.0 (CH7) 1997 CCM 147 HP 12/1999 - 12/2002
2.0 TDi (CH8) 1994 CCM 105 HP 12/1999 - 10/2000
SHUTTLE (RA)
Description Cylinder Capacity Horse Power Year
2.2 16V (RA1) 2156 CCM 150 HP 10/1994 - 02/1998
2.3 16V (RA3, RA5) 2254 CCM 150 HP 10/1997 - 06/2004
ROVER
600 I (RH)
Description Cylinder Capacity Horse Power Year
620 i 1997 CCM 115 HP 08/1993 - 06/1996
620 Si 1997 CCM 131 HP 08/1993 - 02/1999
623 Si 2259 CCM 158 HP 08/1993 - 06/1999
620 Ti Vitesse 1994 CCM 200 HP 05/1994 - 08/1998
620 Sdi 1994 CCM 105 HP 05/1994 - 06/1999
618 i/Si 1850 CCM 115 HP 03/1996 - 02/1999

The Delphi TA1589 Tie Rod End is a replacement steering or suspension joint component that locates connected chassis parts while allowing their intended movement. Its catalogue specification records M14x1.5 thread size, with right-hand thread thread type, front axle left fitting position, and 234 mm length. Match the reference, side, axle position, joint or thread dimensions and vehicle application before fitting; steering geometry should be checked after replacement where applicable.

Function : Tie Rod End
Thread Size : M14x1.5
Thread Type : with right-hand thread
Cone Size [mm] : 12.9
Paired article number : TA1588
Fitting Position : Front Axle Left
Length [mm] : 234
Width [mm] : 45
Height [mm] : 65
  • Vendor DELPHI
  • SKU TA1589
  • Barcode 5012759057728
  • HONDA : 53560-S1A-E01 53560SV4013 53560-SV4-003 53560-SN4-004 53560SM4J62 53560-SM4-004 53560S84A01 53560SX0003 53560-SM4-003
  • ROVER : GSJ407
  • BLUE PRINT : ADH28715
  • BORG & BECK : BTR4485
  • CORTECO : 49399863
  • FEBI BILSTEIN : 12946
  • FEBI BILSTEIN : 15498
  • FEBI BILSTEIN : 21629
  • FEBI BILSTEIN : 24931
  • FEBI BILSTEIN : 42201
  • FIRST LINE : FTR4485
  • KYB : KTR1172
  • LEMFÖRDER : 15441 01
  • LEMFÖRDER : 31508 01
  • MEYLE : 31-16 020 0007
  • MONROE : L40108
  • Schaeffler FAG : 840 0638 10
  • SKF : VKDY 813017
  • TRW : JTE306
  • TRW : JTE537
