Delphi TA1624 Tie Rod End

SKU: TA1624
Your selected vehicle
Only 3 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£11.47 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

MAZDA
121 II (DB)
Description Cylinder Capacity Horse Power Year
1.3 16V (DB3PA) 1324 CCM 53 HP 11/1990 - 03/1996
1.3 i 16V (DB3PA) 1324 CCM 72 HP 11/1990 - 03/1996
323 F Mk IV (BG)
Description Cylinder Capacity Horse Power Year
1.6 (BG6S, BG6P) 1597 CCM 84 HP 09/1989 - 06/1991
1.6 16V (BG6S, BG6P) 1597 CCM 88 HP 03/1991 - 10/1994
1.8 16V (BG8S, BG8P) 1840 CCM 103 HP 08/1989 - 07/1994
1.8 16V GT (BG8S, BG8P) 1840 CCM 128 HP 08/1989 - 07/1994
1.8 4WD (BG8R) 1840 CCM 103 HP 01/1991 - 04/1994
1.8 16V (BG8S, BG8P) 1840 CCM 140 HP 09/1989 - 03/1993
1.6 (BG6S, BG6P) 1597 CCM 90 HP 04/1991 - 04/1994
323 C Mk IV (BG)
Description Cylinder Capacity Horse Power Year
1.3 (BG3S) 1324 CCM 67 HP 09/1989 - 07/1994
1.6 (BG6Z) 1597 CCM 84 HP 09/1989 - 06/1991
1.6 16V (BG6Z) 1597 CCM 88 HP 03/1991 - 10/1994
1.8 16V GT (BG8S) 1840 CCM 128 HP 09/1989 - 03/1993
1.7 D (BG7S) 1720 CCM 56 HP 08/1989 - 07/1994
1.8 16V Turbo 4WD (BG8S) 1840 CCM 185 HP 01/1993 - 07/1994
1.8 16V 4WD (BG8S) 1840 CCM 103 HP 11/1991 - 12/1993
1.8 16V Turbo 4WD (BG8S) 1840 CCM 163 HP 09/1990 - 12/1992
1.3 16V (BG3S) 1324 CCM 73 HP 09/1989 - 07/1994
1.8 16V (BG8S) 1840 CCM 140 HP 09/1989 - 03/1993
1.8 (BG8S) 1840 CCM 130 HP 09/1989 - 06/1993
323 S Mk IV (BG)
Description Cylinder Capacity Horse Power Year
1.3 (BG3P) 1324 CCM 67 HP 09/1989 - 06/1991
1.3 16V (BG3P) 1324 CCM 73 HP 04/1991 - 07/1994
1.6 (BG6S) 1597 CCM 84 HP 09/1989 - 06/1991
1.6 16V (BG6S) 1597 CCM 88 HP 08/1989 - 10/1996
1.8 16V (BG8P) 1840 CCM 103 HP 08/1989 - 07/1994
1.7 D (BG7P) 1720 CCM 56 HP 08/1989 - 07/1994
1.8 16V Turbo 4WD (BG8R) 1840 CCM 163 HP 01/1991 - 07/1994
1.8 16V 4WD 1840 CCM 103 HP 09/1991 - 07/1994
1.8 16V GT (BG8P) 1840 CCM 128 HP 06/1989 - 07/1994
1.6 (BG6S) 1597 CCM 87 HP 06/1989 - 03/1991
323 S Mk V (BA)
Description Cylinder Capacity Horse Power Year
1.3 16V 1324 CCM 73 HP 08/1994 - 09/1998
1.5 16V (BA11) 1489 CCM 88 HP 08/1994 - 09/1998
1.8 16V (BA11) 1840 CCM 114 HP 08/1994 - 09/1998
1.7 TD 1686 CCM 82 HP 05/1994 - 09/1998
2.0 D 1998 CCM 71 HP 10/1996 - 09/1998
323 F Mk V (BA)
Description Cylinder Capacity Horse Power Year
2.0 24V (BAEP) 1995 CCM 144 HP 08/1994 - 09/1998
1.5 16V (BA11) 1489 CCM 88 HP 07/1994 - 09/1998
1.8 16V (BA8P) 1840 CCM 114 HP 08/1994 - 09/1998
323 C Mk V (BA)
Description Cylinder Capacity Horse Power Year
1.3 16V 1324 CCM 73 HP 08/1994 - 09/1998
1.5 16V (BA11) 1489 CCM 88 HP 08/1994 - 09/1998
1.8 16V (BA8P) 1840 CCM 114 HP 08/1994 - 09/1998
323 P Mk V (BA)
Description Cylinder Capacity Horse Power Year
1.3 16V 1324 CCM 73 HP 10/1996 - 09/1998
1.5 16V 1489 CCM 88 HP 10/1996 - 09/1998
2.0 D 1998 CCM 71 HP 10/1996 - 09/1998
DEMIO (DW)
Description Cylinder Capacity Horse Power Year
1.3 16V (DW3W, DW19) 1324 CCM 63 HP 08/1998 - 07/2003
1.3 i 16V (DW3W) 1324 CCM 72 HP 08/1998 - 04/2000
1.5 16V (DW5W) 1498 CCM 75 HP 04/2000 - 07/2003
MX-3 / AZ-3 / PRESSO (EC)
Description Cylinder Capacity Horse Power Year
1.6 1597 CCM 90 HP 05/1991 - 10/1993
1.8 i V6 (ECPSA) 1845 CCM 133 HP 01/1992 - 01/1994
1.6 i 1597 CCM 107 HP 11/1993 - 09/1998
1.8 i V6 (ECPSA) 1845 CCM 129 HP 01/1994 - 10/1997
1.8 i V6 1845 CCM 135 HP 01/1996 - 10/1997
RX-7 Mk III (FD)
Description Cylinder Capacity Horse Power Year
1.3 Twin Turbo (FD3S, FD1031) 1308 CCM 239 HP 07/1992 - 08/2002

The Delphi TA1624 Tie Rod End is a replacement steering or suspension joint component that locates connected chassis parts while allowing their intended movement. Its catalogue specification records M12x1.25 thread size, with right-hand thread thread type, front axle fitting position, and 92 mm length. Match the reference, side, axle position, joint or thread dimensions and vehicle application before fitting; steering geometry should be checked after replacement where applicable.

Function : Tie Rod End
Thread Size : M12x1.25
Thread Type : with right-hand thread
Cone Size [mm] : 13.2
Fitting Position : Front Axle
Length [mm] : 92
Width [mm] : 37
Height [mm] : 73
  • Vendor DELPHI
  • SKU TA1624
  • Barcode 5012759089804
  • MAZDA : 8AB0-32-280 8AB2-32-280 B455-32-280
  • BLUE PRINT : ADM58710
  • BORG & BECK : BTR4570
  • CORTECO : 49399921
  • FEBI BILSTEIN : 12904
  • FIRST LINE : FTR4570
  • KYB : KTR1018
  • LEMFÖRDER : 15478 01
  • LEMFÖRDER : 15478 03
  • MEYLE : 516 020 0002
  • MONROE : L50105
  • Schaeffler FAG : 840 0612 10
  • SKF : VKDY 814016
  • TRW : JTE241
  • TRW : JTE7592
