DELPHI

Delphi TA1649 Tie Rod End

SKU: TA1649
Your selected vehicle
Out of stock
Out of Stock
£23.10 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

BMW
7 (E38)
Description Cylinder Capacity Horse Power Year
730 i, iL 2997 CCM 211 HP 10/1994 - 11/2001
730 i, iL 2997 CCM 218 HP 03/1994 - 02/1996
740 i, iL 3982 CCM 286 HP 03/1994 - 02/1996
750 i, iL 5379 CCM 326 HP 11/1994 - 07/2001
740 i, iL 4398 CCM 286 HP 02/1996 - 07/2001
728 i, iL 2793 CCM 193 HP 08/1995 - 11/2001
735 i, iL 3498 CCM 235 HP 03/1996 - 08/1998
725 tds 2497 CCM 143 HP 04/1996 - 11/2001
730 d 2926 CCM 184 HP 08/1998 - 04/2000
740 d 3901 CCM 245 HP 05/1999 - 11/2001
730 d 2926 CCM 193 HP 04/2000 - 11/2001
735 i, iL 3498 CCM 238 HP 09/1998 - 07/2001

The Delphi TA1649 Tie Rod End is a replacement steering or suspension joint component that locates connected chassis parts while allowing their intended movement. Its catalogue specification records M16x1.5 thread size, with right-hand thread thread type, front axle right fitting position, and 245 mm length. Match the reference, side, axle position, joint or thread dimensions and vehicle application before fitting; steering geometry should be checked after replacement where applicable.

Function : Tie Rod End
Thread Size : M16x1.5
Thread Type : with right-hand thread
Cone Size [mm] : 14.6
Paired article number : TA1648
Fitting Position : Front Axle Right
Length [mm] : 245
Width [mm] : 40
Height [mm] : 80
  • Vendor DELPHI
  • SKU TA1649
  • Barcode 5012759143001
  • BMW : 3221 1141 346
  • BORG & BECK : BTR4582
  • CORTECO : 49399842
  • FEBI BILSTEIN : 11815
  • FEBI BILSTEIN : 27563
  • FIRST LINE : FTR4582
  • LEMFÖRDER : 10694 03
  • MEYLE : 316 020 4351
  • MONROE : L11107
  • Schaeffler FAG : 840 0663 10
  • SKF : VKDY 318530
  • TRW : JTE146
