DELPHI

Delphi TA2641 Tie Rod End

SKU: TA2641
Your selected vehicle
In stock
Orders placed by 17:00 are usually dispatched the same working day
£25.40 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

HONDA
CIVIC VIII Hatchback (FN, FK)
Description Cylinder Capacity Horse Power Year
1.4 (FK1) 1339 CCM 83 HP 09/2005 - 09/2008
1.8 (FN1, FK2) 1799 CCM 140 HP 09/2005 - 12/2011
2.2 CTDi (FK3) 2204 CCM 140 HP 09/2005 - 12/2011
Type R (FN2) 1998 CCM 201 HP 09/2006 - 01/2012
1.4 (FK1, FN4) 1339 CCM 100 HP 10/2008 - 12/2011
2.0 i-VTEC Type R (FN2) 1998 CCM 241 HP 03/2010 - 12/2010

The Delphi TA2641 Tie Rod End is a replacement steering or suspension joint component that locates connected chassis parts while allowing their intended movement. Its catalogue specification records M14x1.5 thread size, with right-hand thread thread type, front axle right fitting position, and 215 mm length. Match the reference, side, axle position, joint or thread dimensions and vehicle application before fitting; steering geometry should be checked after replacement where applicable.

Function : Tie Rod End
Thread Size : M14x1.5
Thread Type : with right-hand thread
Cone Size [mm] : 13.7
Paired article number : TA2640
Fitting Position : Front Axle Right
Length [mm] : 215
Width [mm] : 48
Height [mm] : 72
  • Vendor DELPHI
  • SKU TA2641
  • Barcode 5012759465059
  • HONDA : 53540-SMG-003 53540SMJ003
  • APEC : AST6279
  • APEC : AST6548
  • BLUE PRINT : ADH28774
  • BORG & BECK : BTR5552
  • CORTECO : 49401712
  • FEBI BILSTEIN : 42235
  • FIRST LINE : FTR5552
  • MEYLE : 31-16 020 0054/HD
  • MONROE : L40125
  • NAPA : NST6279
  • NAPA : NST6548
  • SKF : VKDY 813010
  • TRW : JTE2092
