DELPHI

Delphi TA2939 Tie Rod End

SKU: TA2939
Your selected vehicle
Only 4 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£22.90 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

LAND ROVER
RANGE ROVER IV (L405)
Description Cylinder Capacity Horse Power Year
3.0 SDV6 4x4 2993 CCM 249 HP 08/2012 - 01/2016
3.0 TDV6 4x4 2993 CCM 258 HP 08/2012 - 09/2021
4.4 SDV8 4x4 4367 CCM 340 HP 08/2012 - 09/2021
5.0 SCV8 4x4 5000 CCM 510 HP 08/2012 - 09/2021
3.0 SCV6 4x4 2995 CCM 340 HP 10/2013 - 09/2021
3.0 TDV6 4x4 2993 CCM 211 HP 10/2013 - 01/2016
3.0 SDV6 Hybrid 4x4 2993 CCM 340 HP 10/2013 - 09/2021
5.0 V8 4x4 5000 CCM 375 HP 12/2013 - 01/2016
4.4 SDV8 4x4 4367 CCM 313 HP 08/2013 - 09/2021
5.0 SCV8 4x4 5000 CCM 550 HP 06/2015 - 09/2021
3.0 SCV6 4x4 2995 CCM 380 HP 06/2015 - 09/2021
3.0 SDV6 Hybrid 4x4 2993 CCM 354 HP 06/2015 - 09/2021
5.0 SCV8 4x4 5000 CCM 525 HP 11/2017 - 09/2021
5.0 SCV8 4x4 5000 CCM 566 HP 11/2017 - 09/2021
3.0 SDV6 4x4 2993 CCM 275 HP 10/2018 - 09/2021
RANGE ROVER SPORT II (L494)
Description Cylinder Capacity Horse Power Year
5.0 SCV8 4x4 4999 CCM 510 HP 04/2013 - 12/2018
3.0 SCV6 4x4 2995 CCM 340 HP 04/2013 - 12/2019
3.0 SDV6 4x4 2993 CCM 292 HP 04/2013 - 12/2016
3.0 TDV6 4x4 2993 CCM 258 HP 04/2013 - 03/2022
3.0 TDV6 4x4 2993 CCM 211 HP 04/2013 - 12/2018
3.0 SDV6 4x4 2993 CCM 249 HP 04/2013 - 03/2022
4.4 SDV8 4x4 4367 CCM 340 HP 10/2013 - 03/2022
3.0 SDV6 Hybrid 4x4 2993 CCM 340 HP 10/2013 - 03/2022
5.0 SCV8 4x4 4999 CCM 550 HP 01/2014 - 12/2018
3.0 SDV6 4x4 2993 CCM 306 HP 09/2014 - 03/2022
3.0 SCV6 4x4 2995 CCM 380 HP 06/2015 - 12/2018
3.0 SDV6 Hybrid 4x4 2993 CCM 354 HP 06/2015 - 12/2017
2.0 SD4 4x4 1999 CCM 241 HP 08/2016 - 03/2022
2.0 Si4 4x4 1997 CCM 300 HP 10/2017 - 03/2022
5.0 SCV8 4x4 4999 CCM 525 HP 11/2017 - 03/2022

The Delphi TA2939 Tie Rod End is a replacement steering or suspension joint component that locates connected chassis parts while allowing their intended movement. Its catalogue specification records M14.1.5 thread size, with right-hand thread thread type, front axle fitting position, and 130 mm length. Match the reference, side, axle position, joint or thread dimensions and vehicle application before fitting; steering geometry should be checked after replacement where applicable.

Function : Tie Rod End
Thread Size : M14.1.5
Thread Type : with right-hand thread
Cone Size [mm] : 16.6
Fitting Position : Front Axle
Length [mm] : 130
Width [mm] : 48
Height [mm] : 118
  • Vendor DELPHI
  • SKU TA2939
  • ROVER : LR033534
  • LAND ROVER : LR033534
  • APEC : AST6804
  • BORG & BECK : BTR5892
  • FEBI BILSTEIN : 109568
  • FEBI BILSTEIN : 175592
  • FIRST LINE : FTR5892
  • LEMFÖRDER : 37121 01
  • MEYLE : 53-16 020 0017/HD
  • MONROE : L17130
  • NAPA : NST6804
  • SKF : VKDY 311064
  • TRW : JTE2238
