Delphi TA3201 Tie Rod End - 1
Delphi TA3201 Tie Rod End video
Delphi TA3201 Tie Rod End - 1
Delphi TA3201 Tie Rod End video
DELPHI

Delphi TA3201 Tie Rod End

SKU: TA3201
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£22.72 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

BMW
X3 (F25)
Description Cylinder Capacity Horse Power Year
xDrive 28 i 2996 CCM 258 HP 01/2011 - 10/2012
xDrive 30 d 2993 CCM 258 HP 04/2011 - 08/2017
xDrive 35 d 2993 CCM 313 HP 10/2011 - 08/2017
xDrive 20 i 1997 CCM 184 HP 10/2011 - 08/2017
xDrive 35 i 2979 CCM 306 HP 09/2010 - 08/2017
xDrive 20 d 1995 CCM 184 HP 09/2010 - 03/2014
xDrive 28 i 1997 CCM 245 HP 04/2012 - 08/2017
sDrive 18 d 1995 CCM 136 HP 10/2012 - 03/2014
sDrive 18 d 1995 CCM 143 HP 10/2012 - 03/2014
xDrive 20 d 1995 CCM 163 HP 09/2010 - 08/2017
sDrive 18 d 1995 CCM 150 HP 04/2014 - 08/2017
xDrive 20 d 1995 CCM 190 HP 04/2014 - 08/2017
sDrive 20 i 1997 CCM 184 HP 04/2014 - 08/2017
sDrive 20 i 1592 CCM 170 HP 04/2014 - 08/2017
xDrive 30 d 2993 CCM 211 HP 04/2011 - 08/2017
X4 (F26)
Description Cylinder Capacity Horse Power Year
xDrive 20 i 1997 CCM 184 HP 04/2014 - 03/2018
xDrive 28 i 1997 CCM 245 HP 04/2014 - 03/2018
xDrive 35 i 2979 CCM 306 HP 04/2014 - 03/2018
xDrive 20 d 1995 CCM 190 HP 04/2014 - 03/2018
xDrive 30 d 2993 CCM 258 HP 04/2014 - 03/2018
xDrive 35 d 2993 CCM 313 HP 04/2014 - 03/2018
xDrive 20 d 1995 CCM 163 HP 04/2014 - 03/2018
M 40 i 2979 CCM 360 HP 12/2015 - 03/2018
xDrive 30 d 2993 CCM 286 HP 04/2014 - 03/2018
xDrive 30 d 2993 CCM 249 HP 04/2015 - 03/2018
xDrive 30 d 2993 CCM 277 HP 04/2014 - 03/2018

The Delphi TA3201 Tie Rod End is a replacement steering or suspension joint component that locates connected chassis parts while allowing their intended movement. Its catalogue specification records M16x1.5 thread size, with right-hand thread thread type, front axle fitting position, and 193 mm length. Match the reference, side, axle position, joint or thread dimensions and vehicle application before fitting; steering geometry should be checked after replacement where applicable.

Function : Tie Rod End
Thread Size : M16x1.5
Thread Type : with right-hand thread
Cone Size [mm] : 15.4
Fitting Position : Front Axle
Length [mm] : 193
Width [mm] : 43
Height [mm] : 85
  • Vendor DELPHI
  • SKU TA3201
  • Barcode 5012759980200
  • BMW : 3210 6792 674
  • APEC : AST6444
  • BORG & BECK : BTR5836
  • BOSCH : 0 986 140 642
  • CORTECO : 49401873
  • FEBI BILSTEIN : 103114
  • FIRST LINE : FTR5836
  • LEMFÖRDER : 35858 01
  • MEYLE : 316 020 0058
  • MONROE : L11133
  • NAPA : NST6444
  • Schaeffler FAG : 840 1371 10
  • SKF : VKDY 318517
  • TRW : JTE1705
