DELPHI

Delphi TA972 Tie Rod End

SKU: TA972
Your selected vehicle
Only 2 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£11.55 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

OPEL
KADETT E Estate Van (T85)
Description Cylinder Capacity Horse Power Year
1.2 (C70, D70) 1196 CCM 55 HP 09/1984 - 07/1986
1.4 i (C70, D70) 1389 CCM 60 HP 01/1990 - 08/1991
1.6 D (C70, D70) 1598 CCM 54 HP 08/1984 - 08/1988
1.7 D (C70, D70) 1699 CCM 57 HP 08/1988 - 09/1992
1.8 i (C70, D70) 1796 CCM 90 HP 08/1984 - 09/1992
1.6 i (C70, D70) 1598 CCM 75 HP 08/1989 - 09/1993
1.3 N (C70, D70) 1297 CCM 60 HP 09/1984 - 07/1989
KADETT E (T85)
Description Cylinder Capacity Horse Power Year
1.2 (C19, D19) 1196 CCM 55 HP 09/1984 - 07/1986
1.3 N (C19, D19) 1297 CCM 60 HP 09/1984 - 08/1989
1.4 S (C19, D19) 1389 CCM 75 HP 01/1990 - 08/1991
2.0 i (C19, D19) 1998 CCM 115 HP 09/1987 - 05/1992
1.7 D (C19, D19) 1699 CCM 57 HP 02/1989 - 08/1991
1.8 i (C19, D19) 1796 CCM 90 HP 08/1989 - 05/1992
1.3 i Cat (C19, D19) 1297 CCM 60 HP 09/1985 - 08/1991
2.0 i Cat (C19, D19) 1998 CCM 115 HP 03/1987 - 05/1992
2.0 (C19, D19) 1998 CCM 129 HP 01/1986 - 12/1993
KADETT E Hatchback (T85)
Description Cylinder Capacity Horse Power Year
1.2 (C08, C48, D08, D48) 1196 CCM 55 HP 09/1984 - 07/1986
1.3 N (C08, C48, D08, D48) 1297 CCM 60 HP 09/1984 - 08/1991
1.3 S (C08, C48, D08, D48) 1297 CCM 75 HP 09/1984 - 08/1987
1.4 S (C08, C48, D08, D48) 1389 CCM 75 HP 01/1990 - 08/1991
1.6 i (C08, C48, D08, D48) 1598 CCM 75 HP 09/1986 - 08/1991
1.6 S (C08, C48, D08, D48) 1598 CCM 82 HP 09/1986 - 08/1991
1.6 S (C08, D08, C48, D48) 1598 CCM 90 HP 09/1984 - 08/1986
1.8 S (C08, C48, D08, D48) 1796 CCM 84 HP 09/1987 - 08/1991
1.8 GSI (C08, C48, D08, D48) 1796 CCM 115 HP 09/1984 - 08/1986
2.0 GSI (C08, C48, D08, D48) 1998 CCM 115 HP 09/1986 - 08/1991
2.0 GSI (C08, C48, D08, D48) 1998 CCM 129 HP 09/1986 - 08/1991
2.0 GSI 16V (C08, C48, D08, D48) 1998 CCM 150 HP 03/1988 - 08/1991
1.6 D (C08, C48, D08, D48) 1598 CCM 54 HP 09/1984 - 01/1989
1.7 D (C08, C48, D08, D48) 1699 CCM 57 HP 02/1989 - 08/1991
1.4 i (C08, C48, D08, D48) 1389 CCM 60 HP 01/1990 - 08/1991
KADETT E Estate (T85)
Description Cylinder Capacity Horse Power Year
1.2 (C15, C35, D15, D35) 1196 CCM 55 HP 09/1984 - 07/1986
1.3 N (C15, C35, D15, D35) 1297 CCM 60 HP 09/1984 - 08/1991
1.3 S (C15, C35, D15, D35) 1297 CCM 75 HP 09/1984 - 08/1987
1.4 S (C15, C35, D15, D35) 1389 CCM 75 HP 01/1990 - 08/1991
1.6 i (C15, C35, D15, D35) 1598 CCM 75 HP 09/1986 - 08/1991
1.6 (C15, C35, D15, D35) 1598 CCM 82 HP 09/1986 - 08/1991
1.6 S (C15, C35, D35, D15) 1598 CCM 90 HP 09/1984 - 08/1986
2.0 i (C15, C35, D15, D35) 1998 CCM 115 HP 09/1987 - 08/1991
1.6 D (C15, C35, D15, D35) 1598 CCM 54 HP 09/1984 - 01/1989
1.7 D (C15, C35, D15, D35) 1699 CCM 57 HP 02/1989 - 08/1991
1.3 i Cat (C15, C35, D15, D35) 1297 CCM 60 HP 09/1985 - 08/1991
1.6 i Cat (C15, C35, D15, D35) 1598 CCM 75 HP 09/1986 - 08/1991
2.0 i Cat (C15, C35, D15, D35) 1998 CCM 115 HP 09/1987 - 08/1991
1.8 (46) 1796 CCM 111 HP 12/1988 - 08/1991
KADETT E Combo (T85)
Description Cylinder Capacity Horse Power Year
1.3 N (C25, D25) 1297 CCM 60 HP 01/1986 - 12/1989
1.3 S (C25, D25) 1297 CCM 75 HP 01/1986 - 12/1989
1.6 (C25, D25) 1598 CCM 82 HP 09/1986 - 12/1991
1.6 D (C25, D25) 1598 CCM 54 HP 01/1986 - 12/1989
1.7 D (C25, D25) 1699 CCM 57 HP 01/1989 - 07/1994
1.4 S (C25, D25) 1389 CCM 75 HP 07/1989 - 08/1991
1.6 i (C25, D25) 1598 CCM 75 HP 08/1991 - 07/1994
1.4 i (C25, D25) 1389 CCM 60 HP 08/1991 - 07/1994
1.7 D (C25, D25) 1699 CCM 60 HP 07/1992 - 07/1994
KADETT E Convertible (T85)
Description Cylinder Capacity Horse Power Year
1.6 i 1598 CCM 75 HP 10/1986 - 02/1993
2.0 i 1998 CCM 115 HP 10/1986 - 02/1993
1.6 i 1598 CCM 82 HP 07/1989 - 02/1993
1.3 S 1297 CCM 75 HP 03/1987 - 02/1993
1.6 i Cat 1598 CCM 75 HP 10/1987 - 02/1993
2.0 i Cat 1998 CCM 116 HP 10/1986 - 02/1993
VAUXHALL
ASTRA Mk II Hatchback (T85)
Description Cylinder Capacity Horse Power Year
1.2 1196 CCM 60 HP 09/1984 - 08/1991
1.3 1297 CCM 75 HP 09/1984 - 08/1991
1.4 S 1389 CCM 75 HP 01/1990 - 08/1991
1.6 D 1598 CCM 54 HP 09/1984 - 12/1989
1.7 D 1699 CCM 57 HP 09/1988 - 08/1991
1.8 GTE 1796 CCM 112 HP 09/1984 - 08/1991
2.0 GTE 1998 CCM 129 HP 09/1986 - 08/1991
2.0 GTE 16V 1998 CCM 156 HP 05/1988 - 08/1991
1.4 i 1389 CCM 60 HP 01/1990 - 08/1991
1.6 S 1598 CCM 90 HP 09/1984 - 08/1986
1.2 1196 CCM 54 HP 09/1984 - 08/1991
1.9 1998 CCM 149 HP 03/1988 - 08/1991
2.0 1998 CCM 115 HP 09/1986 - 08/1991
ASTRA Mk II Estate (T85)
Description Cylinder Capacity Horse Power Year
1.2 1196 CCM 60 HP 09/1984 - 12/1988
1.3 1297 CCM 75 HP 09/1984 - 08/1991
1.6 1598 CCM 82 HP 09/1984 - 08/1991
1.6 D 1598 CCM 54 HP 09/1984 - 12/1989
1.4 S 1389 CCM 75 HP 01/1989 - 08/1991
1.6 S 1598 CCM 90 HP 09/1984 - 08/1986
1.7 D 1699 CCM 57 HP 02/1989 - 08/1991
1.8 i 1796 CCM 112 HP 01/1990 - 08/1991
ASTRA Mk II Belmont (T85)
Description Cylinder Capacity Horse Power Year
1.3 1297 CCM 75 HP 09/1985 - 08/1991
1.6 1598 CCM 90 HP 09/1985 - 08/1991
1.6 D 1598 CCM 54 HP 09/1985 - 08/1991
1.8 i 1796 CCM 115 HP 09/1985 - 08/1991
1.8 1796 CCM 111 HP 01/1986 - 12/1990
1.4 i 1389 CCM 60 HP 01/1990 - 12/1991
1.6 S 1598 CCM 82 HP 01/1989 - 12/1991
1.7 D 1699 CCM 57 HP 01/1989 - 12/1991
1.4 S 1389 CCM 75 HP 10/1989 - 12/1991
ASTRA Mk II Convertible (T85)
Description Cylinder Capacity Horse Power Year
1.6 i 1598 CCM 82 HP 01/1987 - 12/1991
2.0 i Cat 1998 CCM 115 HP 01/1991 - 08/1993
2.0 i 1998 CCM 115 HP 01/1987 - 12/1991
1.4 S (43) 1389 CCM 75 HP 09/1991 - 09/1993
ASTRAMAX (T85)
Description Cylinder Capacity Horse Power Year
1.3 N 1297 CCM 60 HP 08/1985 - 12/1989
1.3 S 1297 CCM 75 HP 08/1985 - 12/1989
1.4 i 1389 CCM 60 HP 08/1991 - 07/1994
1.4 S 1389 CCM 75 HP 07/1989 - 08/1991
1.6 i 1598 CCM 75 HP 08/1991 - 10/1994
1.6 1598 CCM 82 HP 09/1985 - 12/1991
1.6 D 1598 CCM 54 HP 05/1986 - 06/1990
1.7 D 1699 CCM 57 HP 01/1989 - 07/1994
1.6 1598 CCM 83 HP 12/1986 - 12/1992
DAEWOO
ARANOS
Description Cylinder Capacity Horse Power Year
1.8 1796 CCM 95 HP 01/1995 - 11/1997
ESPERO (KLEJ)
Description Cylinder Capacity Horse Power Year
1.5 16V 1498 CCM 90 HP 02/1995 - 06/1999
1.8 1796 CCM 90 HP 02/1995 - 09/1999
1.8 1796 CCM 95 HP 02/1995 - 06/1999
2.0 1998 CCM 105 HP 02/1995 - 06/1999
LANOS Saloon (KLAT)
Description Cylinder Capacity Horse Power Year
1.3 1349 CCM 75 HP From 05/1997
1.5 1498 CCM 86 HP From 05/1997
1.6 16V 1598 CCM 106 HP From 02/1997
LANOS (KLAT)
Description Cylinder Capacity Horse Power Year
1.3 1349 CCM 75 HP From 05/1997
1.5 1498 CCM 86 HP From 05/1997
1.6 16V 1598 CCM 106 HP From 05/1997
NEXIA
Description Cylinder Capacity Horse Power Year
1.5 (08, 68) 1498 CCM 71 HP 02/1995 - 08/1997
1.5 (08, 68) 1498 CCM 75 HP 02/1995 - 08/1997
1.5 16V (08, 68) 1498 CCM 90 HP 02/1995 - 08/1997
1.5 (08, 68) 1498 CCM 60 HP 08/1996 - 08/1997
NEXIA Saloon
Description Cylinder Capacity Horse Power Year
1.5 (19) 1498 CCM 71 HP 02/1995 - 08/1997
1.5 (19) 1498 CCM 75 HP 02/1995 - 08/1997
1.5 16V (19) 1498 CCM 90 HP 02/1995 - 08/1997
1.5 (19) 1498 CCM 60 HP 08/1996 - 08/1997

The Delphi TA972 Tie Rod End is a replacement steering or suspension joint component that locates connected chassis parts while allowing their intended movement. Its catalogue specification records M16x1.5 thread size, with right-hand thread thread type, front axle left fitting position, and 85 mm length. Match the reference, side, axle position, joint or thread dimensions and vehicle application before fitting; steering geometry should be checked after replacement where applicable.

Function : Tie Rod End
Thread Size : M16x1.5
Thread Type : with right-hand thread
Cone Size [mm] : 12.8
Paired article number : TA965
Fitting Position : Front Axle Left
Length [mm] : 85
Width [mm] : 45
Height [mm] : 77
  • Vendor DELPHI
  • SKU TA972
  • Barcode 5012759852248
  • OPEL : 90140007 0324039 324039
  • VAUXHALL : 90140007
  • DAEWOO : 07846495 26001807 96275018
  • PONTIAC : 26001807
  • BLUE PRINT : ADG08716
  • BORG & BECK : BTR4121
  • CORTECO : 49400475
  • FEBI BILSTEIN : 02635
  • FIRST LINE : FTR4121
  • LEMFÖRDER : 12173 02
  • LEMFÖRDER : 12173 04
  • MEYLE : 616 020 5377
  • MONROE : L24150
  • Schaeffler FAG : 840 1192 10
  • SKF : VKDY 315032
  • TRW : JTE220
