DELPHI

Delphi TC3690 Control/Trailing Arm, wheel suspension

SKU: TC3690
Your selected vehicle
Only 2 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£77.04 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

SUZUKI
GRAND VITARA II (JT, TE, TD)
Description Cylinder Capacity Horse Power Year
1.6 All-wheel Drive (JB416) 1586 CCM 106 HP 04/2005 - 02/2015
2.0 All-wheel Drive (TD54V, JB420) 1995 CCM 140 HP 10/2005 - 02/2015
1.9 DDiS All-wheel Drive (JT419, TD44, JB419WD, JB419XD,... 1870 CCM 129 HP 10/2005 - 02/2015
1.6 All-wheel Drive (TA74, JB416) 1586 CCM 99 HP 09/2005 - 02/2015
3.2 All-wheel Drive (TDB4, JT632, JB632) 3195 CCM 233 HP 01/2009 - 02/2015
2.4 All-wheel Drive (JB424) 2393 CCM 169 HP From 01/2009
2.4 All-wheel Drive (JT424, JB424, TDA4) 2393 CCM 166 HP From 01/2009
3.2 All-wheel Drive (JB632, TDB4) 3195 CCM 224 HP 06/2008 - 02/2015
1.9 DDiS (JB419WD, JB419XD) 1870 CCM 129 HP 03/2006 - 08/2008

The Delphi TC3690 Control/Trailing Arm, wheel suspension is a replacement steering or suspension joint component that locates connected chassis parts while allowing their intended movement. Its catalogue specification records front axle right and lower fitting position, sheet Steel construction, Control Arm control/trailing arm type, and with ball joint. Match the reference, side, axle position, joint or thread dimensions and vehicle application before fitting; steering geometry should be checked after replacement where applicable.

Function : Control/Trailing Arm, wheel suspension
Fitting Position : Front Axle Right
Fitting Position : Lower
Material : Sheet Steel
Paired article number : TC3689
Control/Trailing Arm Type : Control Arm
Supplementary Article/Supplementary Info 2 : with ball joint
Length [mm] : 405
Width [mm] : 403
Height [mm] : 90
  • Vendor DELPHI
  • SKU TC3690
  • Barcode 5012759991794
  • SUZUKI : 4520165J00 4520178K00
  • APEC : AST2613
  • BLUE PRINT : ADK88636
  • BORG & BECK : BCA7049
  • BOSCH : 0 986 141 940
  • CORTECO : 49398750
  • FEBI BILSTEIN : 42292
  • FIRST LINE : FCA7049
  • MEYLE : 34-16 050 0018
  • MONROE : L24551
  • NAPA : NST2613
  • SKF : VKDS 826010 B
  • TRW : JTC1642
  • TRW : JTC7958
