Gates 5075XS Timing Belt - 1
Gates 5075XS Timing Belt video
Gates 5075XS Timing Belt - 1
Gates 5075XS Timing Belt video
GATES

Gates 5075XS Timing Belt

SKU: 5075XS
Your selected vehicle
Only 1 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£39.23 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

MITSUBISHI
CORDIA (A21_A, AB, AC)
Description Cylinder Capacity Horse Power Year
1.6 GSL (A212A) 1597 CCM 75 HP 10/1982 - 12/1986
1.8 GSL (A215A) 1755 CCM 90 HP 10/1986 - 07/1989
1.8 Turbo ECi (A213A) 1795 CCM 136 HP 10/1984 - 07/1989
ECLIPSE   (D2_A)
Description Cylinder Capacity Horse Power Year
1.8 (D21A) 1755 CCM 92 HP 12/1989 - 03/1994
GALANT Mk II (A16_)
Description Cylinder Capacity Horse Power Year
1.6 GLX (A161A) 1597 CCM 75 HP 09/1980 - 05/1984
2.0 GLS (A163) 1997 CCM 102 HP 09/1980 - 05/1984
2.0 Turbo ECi (A164) 1997 CCM 170 HP 05/1982 - 05/1984
GALANT Mk II Station Wagon (A16_V)
Description Cylinder Capacity Horse Power Year
1.6 GLX (A161V) 1597 CCM 75 HP 09/1980 - 05/1984
2.0 GLX (A163V) 1997 CCM 102 HP 09/1980 - 06/1983
GALANT Mk III (E1_A)
Description Cylinder Capacity Horse Power Year
1.6 GLX (E11A) 1597 CCM 75 HP 06/1984 - 04/1990
2.0 GLS (E15A) 1997 CCM 90 HP 06/1986 - 04/1990
2.0 GLS (E15A) 1997 CCM 102 HP 06/1984 - 04/1990
2.0 Turbo ECi (E15A) 1997 CCM 150 HP 06/1984 - 04/1990
GALANT Mk IV Saloon (E3_A)
Description Cylinder Capacity Horse Power Year
1.8 (E32A) 1755 CCM 86 HP 11/1987 - 08/1990
1.8 (E32A) 1755 CCM 90 HP 11/1987 - 10/1992
GALANT Mk IV (E3_A)
Description Cylinder Capacity Horse Power Year
1.8 (E32A) 1755 CCM 90 HP 11/1988 - 10/1992
1.8 1755 CCM 86 HP 11/1988 - 10/1992
L 300 / DELICA II Van (L03_P)
Description Cylinder Capacity Horse Power Year
1.8 (L035P) 1795 CCM 82 HP 03/1983 - 10/1986
L 300 / DELICA II Bus (L03_P/G, L0_2P)
Description Cylinder Capacity Horse Power Year
1.8 4WD (L035G) 1795 CCM 82 HP 08/1984 - 02/1987
1.8 (L035P) 1795 CCM 82 HP 03/1983 - 10/1986
L 300 III Bus (P0_W, P1_W, P2_W, P3_W)
Description Cylinder Capacity Horse Power Year
2.0 4WD (P23W, P03W, P13W) 1997 CCM 88 HP 12/1986 - 05/2004
2.0 (P03W, P13W) 1997 CCM 87 HP 11/1986 - 05/2004
2.0 4WD (P23W, P03W, P13W) 1997 CCM 90 HP 11/1986 - 05/2004
2.0 (P03W, P13W) 1997 CCM 90 HP 11/1986 - 05/2004
2.0 (P03W, P13W) 1997 CCM 88 HP 11/1986 - 07/1988
L 300 III Van (P0_V, P1_V, P2_V)
Description Cylinder Capacity Horse Power Year
2.0 (P03V, P13V) 1997 CCM 87 HP 11/1986 - 05/1996
L200 (K3_T, K2_T, K1_T, K0_T)
Description Cylinder Capacity Horse Power Year
2.0 1997 CCM 91 HP 10/1986 - 04/1994
2.0 4WD 1997 CCM 86 HP 02/1987 - 05/1994
LANCER   (A17_)
Description Cylinder Capacity Horse Power Year
2.0 Turbo ECi (A176) 1997 CCM 170 HP 03/1981 - 02/1983
SAPPORO Mk II (A16_A)
Description Cylinder Capacity Horse Power Year
2.0 GSL (A164A) 1997 CCM 102 HP 08/1980 - 08/1983
2.0 GSR (A164A) 1997 CCM 112 HP 08/1980 - 09/1984
2.0 Turbo ECi (A164) 1997 CCM 170 HP 08/1982 - 08/1983
SPACE WAGON (D0_V/W)
Description Cylinder Capacity Horse Power Year
1.8 GLX (D05V, D05W) 1755 CCM 90 HP 01/1984 - 12/1988
2.0 GLX (D04W) 1997 CCM 84 HP 06/1986 - 05/1988
2.0 GLX 4WD (D08W) 1997 CCM 84 HP 06/1986 - 05/1988
2.0 GLXi (D04W) 1997 CCM 101 HP 06/1988 - 04/1991
2.0 GLXi 4WD (D08W) 1997 CCM 101 HP 06/1988 - 04/1991
2.0 4WD (D08W) 1997 CCM 102 HP 03/1985 - 04/1991
1.8 4WD (D05V, D05W) 1755 CCM 90 HP 10/1987 - 08/1988
STARION (A18_A)
Description Cylinder Capacity Horse Power Year
2.0 Turbo ECi (A183A) 1997 CCM 170 HP 06/1982 - 12/1985
2.0 Turbo ECi (A183A) 1997 CCM 180 HP 05/1985 - 08/1987
TREDIA (A21_)
Description Cylinder Capacity Horse Power Year
1.6 GLS (A212) 1597 CCM 75 HP 09/1982 - 10/1987
1.8 GLS (A215) 1755 CCM 90 HP 08/1984 - 07/1986
1.8 Turbo (A215A) 1796 CCM 136 HP 08/1984 - 07/1986
1.8 GLS 4WD (A215G) 1755 CCM 90 HP 04/1985 - 07/1986
HYUNDAI
SONATA   (Y-2)
Description Cylinder Capacity Horse Power Year
2.0 i 1997 CCM 109 HP 01/1991 - 10/1993
1.8 i 1796 CCM 95 HP 09/1988 - 10/1993
2.0 i 1997 CCM 101 HP 09/1988 - 08/1991
1.8 1796 CCM 99 HP 06/1989 - 03/1991
STELLAR (F31_, SF2_)
Description Cylinder Capacity Horse Power Year
2.0 GSL 1997 CCM 83 HP 09/1986 - 12/1989

The Gates 5075XS Timing Belt is a replacement belt-drive component that helps transmit drive between the relevant engine pulleys while maintaining the specified belt path. Its catalogue specification records Fiberglass tensile cord material, HNBR (hydrogenated nitrile butadiene rubber) belt material, black colour, and 122 teeth. Match the reference, belt profile or pulley dimensions, tooth data, driven units and engine application before fitting; observe the specified tensioning and timing procedure.

Function : Timing Belt
Article number of the recommended special tool : STT-1
Tensile Cord Material : Fiberglass
Belt Material : HNBR (hydrogenated nitrile butadiene rubber)
Colour : black
Number of Teeth : 122
Width [mm] : 19
Tooth Pitch [mm] : 9.525
Length [mm] : 1,162
  • Vendor GATES
  • SKU 5075XS
  • Barcode 5412571008647
  • MITSUBISHI : MD015701 MD041390 MD098491 MD102249 MD113790 MD140228 MD197136 XD140228
  • HYUNDAI : 24132-32010 24312-32820 24312-32830
  • DANA : PMTB116
  • BLUE PRINT : ADC47503
  • LEMFÖRDER : 18637 01
  • GATES : 5075
  • GATES : 859715075
