Gates 5105 Timing Belt - 1
Gates 5105 Timing Belt video
Gates 5105 Timing Belt - 1
Gates 5105 Timing Belt video
GATES

Gates 5105 Timing Belt

SKU: 5105
Your selected vehicle
Out of stock
Out of Stock
£20.74 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

NISSAN
BLUEBIRD (U11)
Description Cylinder Capacity Horse Power Year
2.0 i 1974 CCM 105 HP 04/1984 - 01/1988
BLUEBIRD Station Wagon (WU11)
Description Cylinder Capacity Horse Power Year
2.0 1974 CCM 102 HP 04/1986 - 09/1990
2.0 i 1974 CCM 105 HP 04/1984 - 12/1990
2.0 i 1974 CCM 115 HP 09/1988 - 09/1990
BLUEBIRD (T72 , T12, U12)
Description Cylinder Capacity Horse Power Year
2.0 (T12) 1974 CCM 102 HP 12/1985 - 12/1987
2.0 i (HLT72, T12) 1974 CCM 105 HP 12/1985 - 12/1990
BLUEBIRD Hatchback (T72, T12)
Description Cylinder Capacity Horse Power Year
2.0 (T12) 1974 CCM 102 HP 12/1985 - 12/1987
2.0 i (FHLT72, T12) 1974 CCM 105 HP 12/1985 - 12/1990
2.0 i 1974 CCM 115 HP 09/1988 - 09/1990
PRAIRIE (M10, NM10)
Description Cylinder Capacity Horse Power Year
2.0 4x4 (NM10) 1974 CCM 92 HP 06/1986 - 09/1988
2.0 1974 CCM 105 HP 01/1986 - 09/1988
2.0 4x4 1974 CCM 105 HP 01/1986 - 09/1988
PRAIRIE PRO (M11)
Description Cylinder Capacity Horse Power Year
2.0 i 1974 CCM 98 HP 10/1988 - 04/1992
2.0 i 4x4 1974 CCM 98 HP 10/1988 - 12/1992
2.0 1974 CCM 105 HP 09/1990 - 03/1992
2.0 4x4 1974 CCM 105 HP 09/1990 - 03/1992

The Gates 5105 Timing Belt is a replacement belt-drive component that helps transmit drive between the relevant engine pulleys while maintaining the specified belt path. Its catalogue specification records Polychloroprene (Neoprene) belt material, 98 teeth, 19 mm width, and 933 mm length. Match the reference, belt profile or pulley dimensions, tooth data, driven units and engine application before fitting; observe the specified tensioning and timing procedure.

Function : Timing Belt
Article number of the recommended special tool : STT-1
Belt Material : Polychloroprene (Neoprene)
Number of Teeth : 98
Width [mm] : 19
Tooth Pitch [mm] : 9.525
Length [mm] : 933
Driven Units : Camshaft
  • Vendor GATES
  • SKU 5105
  • Barcode 5412571003383
  • NISSAN : 13028-D1700 13028-20R00 13028-20R25 13028-D1725
  • DANA : PMTB54
  • APEC : ADS1288R
  • APEC : AWB1649
  • APEC : BCY1232
  • APEC : MCY309
  • BLUE PRINT : ADG04414
  • BLUE PRINT : ADG053111
  • BORG & BECK : BBW1712
  • BORG & BECK : BEM3896
  • BORG & BECK : BWK160
  • BOSCH : 0 986 475 847
  • BOSCH : 1 987 949 130
  • BREMBO : A 12 298
  • BREMBO : M 23 084
  • BREMBO : T 23 112
  • CORTECO : 19018561
  • CORTECO : 19026084
  • DELPHI : BG2191
  • DELPHI : LH6738
  • DELPHI : LM70001
  • DELPHI : LW39035
  • FEBI BILSTEIN : 05577
  • FEBI BILSTEIN : 08838
  • FEBI BILSTEIN : 174068
  • FEBI BILSTEIN : 183673
  • FEBI BILSTEIN : 32272
  • FEBI BILSTEIN : 35220
  • FIRST LINE : FBK160
  • FIRST LINE : FEM3896
  • FTE : 9210098
  • GATES : AWS2459
  • GATES : ETM1130
  • LEMFÖRDER : 18553 01
  • MAHLE : KL 174
  • MAHLE : MG 615
  • MEYLE : 014 033 0045
  • NAPA : NDS1288R
  • NAPA : PWB1649
  • Shaftec : P106R
  • Shaftec : P106RSF
  • SKF : VKBA 596
  • TRW : BWB168
  • TRW : BWD293
  • TRW : PHD991
  • TRW : PMD159
  • UFI : 24.007.00
  • GATES : 859515105
