Gates 5146 Timing Belt

SKU: 5146
Your selected vehicle
Out of stock
Out of Stock
£45.03 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

NISSAN
300C (Y30)
Description Cylinder Capacity Horse Power Year
3.0 i 2960 CCM 154 HP 05/1984 - 05/1988
300C (Y30)
Description Cylinder Capacity Horse Power Year
3.0 i 2960 CCM 154 HP 05/1984 - 05/1988
300ZX (Z31)
Description Cylinder Capacity Horse Power Year
3.0 Turbo 2960 CCM 228 HP 04/1984 - 10/1990
300ZX Coupe (Z31)
Description Cylinder Capacity Horse Power Year
3.0 Turbo 2960 CCM 228 HP 04/1984 - 10/1990
3.0 Turbo 2960 CCM 203 HP 05/1987 - 10/1990
MAXIMA III (J30)
Description Cylinder Capacity Horse Power Year
3.0 i 2960 CCM 170 HP 10/1988 - 06/1994
3.0 2960 CCM 174 HP 10/1988 - 06/1994
PATHFINDER I (WD21)
Description Cylinder Capacity Horse Power Year
3.0 4WD 2960 CCM 155 HP 09/1991 - 10/1995
3.0 4WD 2960 CCM 148 HP 07/1986 - 10/1995
TERRANO   (WD21)
Description Cylinder Capacity Horse Power Year
3.0 i 4WD 2960 CCM 148 HP 01/1990 - 12/1995
LOTUS
ECLAT
Description Cylinder Capacity Horse Power Year
2.2 2174 CCM 162 HP 05/1980 - 08/1986
INFINITI
M30 Coupe
Description Cylinder Capacity Horse Power Year
3.0 2960 CCM 164 HP 01/1989 - 12/1993
M30 Convertible
Description Cylinder Capacity Horse Power Year
3.0 2960 CCM 164 HP 01/1990 - 12/1993

The Gates 5146 Timing Belt is a replacement belt-drive component that helps transmit drive between the relevant engine pulleys while maintaining the specified belt path. Its catalogue specification records Fiberglass tensile cord material, Polychloroprene (Neoprene) belt material, black colour, and 133 teeth. Match the reference, belt profile or pulley dimensions, tooth data, driven units and engine application before fitting; observe the specified tensioning and timing procedure.

Function : Timing Belt
Tensile Cord Material : Fiberglass
Belt Material : Polychloroprene (Neoprene)
Colour : black
Number of Teeth : 133
Width [mm] : 25.4
Tooth Pitch [mm] : 9.525
Length [mm] : 1,267
Construction Year to : 12.1989
Driven Units : Camshaft
  • Vendor GATES
  • SKU 5146
  • Barcode 5412571025705
  • NISSAN : 13028-12G00 AY440-NS020 AY440-NS120 13028-16E10 13028-16E00 13028-85E00 13028-85E85 13028-V5200 13028-V5201 13028-V5220 13028-V5221
  • DANA : PMTB58 PMTB59
  • APEC : AWB1304
  • APEC : BSH1001
  • APEC : DSK179
  • APEC : SDK6033
  • APEC : SHU187
  • BLUE PRINT : ADN17511
  • BLUE PRINT : ADR164314
  • BOSCH : 0 986 478 105
  • BOSCH : 0 986 479 831
  • BREMBO : A 12 B50
  • BREMBO : M 85 032
  • DELPHI : BG2217
  • DELPHI : LM70022
  • DENSO : IT16TT
  • DENSO : PT16EPR-L13
  • FEBI BILSTEIN : 09071
  • FEBI BILSTEIN : 24507
  • FEBI BILSTEIN : 29450
  • FEBI BILSTEIN : 37549
  • FTE : 9072003
  • FTE : 9082382
  • LEMFÖRDER : 12989 01
  • LEMFÖRDER : 18524 01
  • MINTEX : MLR5
  • NAPA : NBS1002
  • NAPA : PWB1304
  • Schaeffler FAG : 713 6679 60
  • SKF : VKBA 6509
  • SKF : VKBD 80343 S2
  • TEXTAR : 91005700
  • TRW : DF1013
  • TRW : DF4382
  • VALEO : 186230
  • WAI : M5-146
  • GATES : 859515146
